Omron H7CX-A4S-N AC100-240 — Electronic Timers & Counters

Omron H7CX-A4S-N AC100-240 Counter, LCD, 4-char, 100-240 VAC, discontinued

MPNH7CX-A4S-N AC100-240
Active

Omron H7CX-A4S-N AC100-240 Counters, Hour Meters — now discontinued, supplied from remaining surplus and broker stock.

$338.83Ref. price · indicative, final on quote
Omron H7CX-A4S-N AC100-240 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

H7CX-A4S-N AC100-240 — Identification
ParameterValue
SeriesH7CX
H7CX-A4S-N AC100-240 — Function & Modes
ParameterValue
Device typePreset, Totalizer
Operating modeUp, Down, Command, Individual, Quadrature
H7CX-A4S-N AC100-240 — Timing & Counting
ParameterValue
Count rate30Hz, 5kHz
Reset methodExternal, Front Panel, Programmable
H7CX-A4S-N AC100-240 — Electrical
ParameterValue
Supply voltage100 ~ 240VAC
H7CX-A4S-N AC100-240 — I/O & Contacts
ParameterValue
Input typeNo Voltage, Voltage
Output typeSolid State
H7CX-A4S-N AC100-240 — Display
ParameterValue
Display typeLCD - Dual Color Characters, Backlight
Characters per row4, 4
Character height0.472" (12.00mm), 0.236" (6.00mm)
H7CX-A4S-N AC100-240 — Mechanical
ParameterValue
Mounting typePanel Mount
Panel cutout dimensionsSquare - 45.00mm x 45.00mm
Termination styleScrew Terminal
H7CX-A4S-N AC100-240 — Environmental
ParameterValue
Operating temperature range-10°C ~ 55°C
Ingress protection (IP)IP66 - Dust Tight, Water Resistant

Product details

Comparison with sibling models

Compared to the H7CX-A4 AC100-240, which uses a relay output, the H7CX-A4S-N AC100-240 switches via solid-state output — no contact wear for high-cycle applications. The H7CX-A11S-N AC100-240 offers a 6-character display and octal plug-in terminals instead of the 4-character screw-terminal layout here; pick that variant when a larger display or quick-disconnect wiring is required.

Omron lists the H7CX-A4S-N AC100-240 as discontinued. No official successor is named in the evidence.

MPN
H7CX-A4S-N AC100-240
