Omron H7CX-R11W-N AC100-240 Counters, Hour Meters — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Series | H7CX |
| Parameter | Value |
|---|---|
| Device type | Tachometer |
| Operating mode | Up |
| Parameter | Value |
|---|---|
| Count rate | 30Hz, 5kHz |
| Reset method | Non-Resettable |
| Parameter | Value |
|---|---|
| Supply voltage | 100 ~ 240VAC |
| Parameter | Value |
|---|---|
| Input type | No Voltage, Voltage |
| Output type | Relay |
| Parameter | Value |
|---|---|
| Display type | LCD - Dual Color Characters, Backlight |
| Characters per row | 6, 6 |
| Character height | 0.394" (10.00mm), 0.236" (6.00mm) |
| Parameter | Value |
|---|---|
| Mounting type | Panel Mount |
| Panel cutout dimensions | Square - 45.00mm x 45.00mm |
| Termination style | Plug In, 11 Pin (Octal) |
| Parameter | Value |
|---|---|
| Operating temperature range | -10°C ~ 55°C |
| Ingress protection (IP) | IP66 - Dust Tight, Water Resistant |
The H7CX-R11W-N AC100-240 is an Omron H7CX series tachometer with a 6-character LCD display, dual-color backlight, and relay output. It accepts 100-240 VAC supply and counts at 30 Hz or 5 kHz selectable rate. The front panel is sealed to IP66, and the unit mounts in a 45 mm square cutout with an 11-pin octal plug-in base.
Omron has discontinued the H7CX-R11W-N AC100-240.
