Omron J7KN22D0124 — Contactors

J7KN22D0124 Contactor, 3NO 24V Coil, 22A AC-3, 11kW

MPNJ7KN22D0124

Omron J7KN22D0124, J7KN series, 3-pole contactor, 3NO main contacts + 1NC auxiliary, 24 V AC coil, 22 A AC-3 switching current, 11 kW switching power, DIN rail and screw mount.

$45.85 – $105.23Ref. price · indicative, final on quote
Omron J7KN22D0124 datasheet (PDF)
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

J7KN22D0124 — Specifications
ParameterValue
Poles3
SeriesJ7KN
HP rating15
MountingDIN Rail Mount;Screw
Termination typeScrew Terminal
Coil voltage - AC24 V
Switching power - AC11 kW
Contact configuration3NO
Switching current - AC22 A
Switching current - DC2.5 A
Switching voltage - AC690 V
Switching voltage - DC220 V
Auxiliary contact configuration1NC

Product details

Rated for motor loads at 24 V AC coil

The J7KN22D0124: It switches AC loads up to 22 A in AC-3 duty (motor starting) and handles 11 kW at 400 V, which covers small pumps, fans, and conveyors in panel builds.

Mounting and terminal details

Mounts on DIN rail or directly with screws — the dual-mount option gives panel builders flexibility when the rail is full or the enclosure backplate is drilled for fixed hardware. Screw terminals on both coil and power circuits accept standard ring or fork lugs, which simplifies field wiring and avoids the need for special crimp tools.

Frequently asked questions

What is the switching capacity of J7KN22D0124?

It switches 22 A AC in AC-3 duty (motor loads) and 2.5 A DC. The AC switching power is 11 kW at 400 V, which covers motors up to 15 HP. For DC loads, the 2.5 A rating at 220 V is typical for solenoid or brake control.
