Omron K8AK-TS1 100-240VAC

Omron K8AK-TS1 100-240VAC Temperature Monitoring Relay, SPDT

MPN K8AK-TS1 100-240VAC
Active

Omron K8AK-TS1, K8AK Series, Temperature Monitoring Relay, SPDT (1 Form C), 100-240VAC Supply, DIN Rail Mount, Active.

$31.20 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

K8AK-TS1 100-240VAC specifications
ParameterValue
SeriesK8AK
Output signalRelay
Product typeTemperature Monitoring
Supply voltage100 to 240VAC
MountingDIN Rail
Temp operating max60 °C
Temp operating min-20 °C
PackageBulk

Product details

Temperature Monitoring Relay for Thermistor Motor Protection

The K8AK-TS1 100-240VAC: The K8AK-TS1 is a dedicated temperature monitoring relay from Omron's K8AK series, designed specifically for thermistor-based motor protection. It monitors motor winding temperature via a PTC thermistor input and trips the SPDT relay output when the threshold is exceeded, protecting the motor from overheating. It runs on a universal 100-240VAC supply and mounts directly on DIN rail.

Key Specifications – What You're Working With

Output is a single-pole double-throw relay rated 5A at 250VAC – suitable for signalling to a PLC, contactor coil, or alarm circuit. The unit has no built-in delay; it reacts immediately to the thermistor condition. Operating temperature range is -20°C to 60°C, covering most industrial cabinet environments.

MPN
K8AK-TS1 100-240VAC
