What this supply delivers for a control panel
The Omron S8FS-G30024C is a 300 W switching power supply that holds the unit on the grid for a 24 V DC control bus. The 300 W rating means it can feed a mix of PLC racks, DC coils, and indicator loads up to 12.5 A continuous at 24 V DC — enough for a medium-sized cabinet, provided you account for inrush on capacitive loads at startup. It carries UL 508 listing and cUL/cUR marks, so it is accepted for panel builds in North America. The SEMI F47-0706 compliance at 200 V AC input means it rides through voltage sags down to 50% of nominal for 200 ms — a useful margin if this supply feeds semiconductor fab equipment or any line where dip tolerance matters.
Direct mount — no DIN rail bracket in the package, so plan for screw-down onto a backplate or sub-panel. The housing is aluminum and stainless steel, which sheds heat better than a plastic case but means you need a clean earth bond to the chassis. Screw terminals accept up to 12 AWG; strip length and torque are the usual 0.5–0.6 N·m range for this wire class. Dimensions are 1.61 in wide by 4.02 in tall by 7.39 in deep — it is a narrow footprint, so it fits between DIN-rail terminal blocks if you leave breathing space above and below for convection.
Protection features and diagnostics
Built-in overload and overvoltage protection with automatic reset, so a temporary fault on the DC bus clears itself without a manual power cycle. The green LED gives a quick visual that the output is within regulation. Maximum output noise is 150 mV — acceptable for digital loads but worth checking if you have sensitive analog transducers on the same rail. Startup time is 1,000 msec maximum, which is typical for a 300 W switcher; sequence your downstream contactors to wait that long before pulling load.
