What It Is and Key Ratings
The Omron S8VKR10 is a redundancy module from the S8VK-R series, designed to combine two power supplies for N+1 redundancy or increased capacity. Its single adjustable output is rated for 10 A continuous, fed from two inputs rated 5–30 V each. That adjustability is useful when you need to fine-tune the output to compensate for voltage drops or match a load slightly off the nominal rail. MTBF is 720000 hours. Operating temperature range is -40 to 70 °C. Termination is screw-type, IP20 protected. Insulation voltage 1 kV.
Mounting and Physical Fit
Width 32 mm, height 94.7 mm, depth 110 mm. Output rated 10 A.
