Omron SRT2-OD04-1

SRT2-OD04-1 Output Module, 4 Solid State, 24VDC

MPN SRT2-OD04-1
Active

SRT2-OD04-1 Output Module, 4 Solid State Outputs, 24VDC, DIN Rail, Screw Terminal.

$325.12 – $335.21 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

SRT2-OD04-1 specifications
ParameterValue
SeriesSRT2
Product typeOutput Module
Supply voltage24 VDC
MountingDIN Rail
Temp operating max55 °C
Temp operating min0 °C
Weight0.176 lb (79.83 g)
PackageBulk

Product details

The SRT2-OD04-1 is a DIN-rail mounted output module from the SRT2 series, providing 4 solid-state outputs at 24VDC. It terminates via screw terminals and holds CE, CSA, and UL approvals. The module is designed for use with C Series devices, per the catalog listing.

Solid-state switching and installation

Four solid-state outputs switch loads without mechanical contact wear, suitable for frequent cycling applications. The module operates over 0°C to 55°C. Mount the module on DIN rail and wire with screw terminals; strip length for solid or stranded wire follows the terminal manufacturer's recommendation.

Compared to CP1W-32ET

The CP1W-32ET provides 32 solid-state outputs and carries Lloyd's and NK approvals in addition to CE. The SRT2-OD04-1 is not a footprint or protocol substitute.

MPN
SRT2-OD04-1
