Omron SRT2-VID08S, 8-point digital input module, 24VDC, screw terminals, DIN rail, CE/CSA/UL.
| Parameter | Value |
|---|---|
| Series | SRT2 |
| For use with / related products | C Series |
| Parameter | Value |
|---|---|
| Digital inputs (count and type) | 8 - Digital |
| Parameter | Value |
|---|---|
| Supply voltage | 24VDC |
| Parameter | Value |
|---|---|
| Operating temperature range | -10°C ~ 55°C |
| Parameter | Value |
|---|---|
| Termination style | Screw Terminal |
| Mounting type | DIN Rail |
| Parameter | Value |
|---|---|
| Agency approvals | CE, CSA, UL |
| Parameter | Value |
|---|---|
| Type | Input Module |
| Weight | 0.165 lb (74.84 g) |
SRT2-VID08S is an 8-point digital input module from the Omron SRT2 series, built for C Series PLC racks. Screw terminals accept 24VDC field wiring; the module snaps onto a DIN rail. Carries CE, CSA, and UL approvals, and operates from -10°C to 55°C.
It is an input module with 8 digital inputs.
CE, CSA, and UL approvals are listed on the specification.
