Omron CJ1W-TC003

Omron CJ1W-TC003 Temp Control, 2 Analog I/O

MPN CJ1W-TC003
End of Life

Omron CJ1W-TC003, a Temperature Control Module for the CJ series, with 2 analog inputs for thermocouple types B, J, K, L, R, S, T and 2 solid state outputs, DIN rail mount, screw terminals.

$1,040.38 – $1,071.81 Ref. price · indicative, final on quote
Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

CJ1W-TC003 specifications
ParameterValue
SeriesCJ1 W
Product typeTemperature Control Module
MountingDIN Rail
Weight0.331 lb (150.14 g)
PackageBulk

Product details

Lead

The Omron CJ1W-TC003 is a Temperature Control Module that fits the CJ PLC series, giving you 2 analog inputs that cover thermocouple types B, J, K, L, R, S, T and 2 solid state outputs. That covers most common industrial temp loops — from oven zones to motor bearing wells — without needing a separate signal conditioner. That means no extra panel work if you're swapping in a similar slot.

Compared to siblings

The CJ1W-TC002 gives you 4 analog inputs and 4 outputs in the same form factor — that's your go-to for multi-zone ovens or multiple bearing temp points on a single card. The CJ1W-TC104 is the RTD-only sibling (Pt100, etc.), also 2 inputs and 2 outputs but with a different sensor front end. If you wire in a thermocouple now, the TC003 is the one; if you need resistance probes, step to the TC104.

Carries CE, cULus, Lloyd, and NK approvals — so it's at home in a marine engine room, an industrial furnace control panel, or a food-processing line. The CJ series backplane handles the power and communications; no separate module-side power supply needed.

Sourcing angle

For procurement: this is an active, widely distributed part. Send an RFQ with your target quantity and we'll quote against current factory lead times. No surplus premium, no broker lottery — straight through the authorized channel.

MPN
CJ1W-TC003
