Omron E5EC-PR4D5M-014

Omron E5EC-PR4D5M-014 Process Controller, 6 Relay Outputs

MPN E5EC-PR4D5M-014
Active

Omron E5EC-PR4D5M-014 process/temperature controller, 6 relay outputs, RS-485 Modbus, 24 VAC/DC supply, IP66 front panel, 1/8 DIN panel mount.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

E5EC-PR4D5M-014 specifications
ParameterValue
SeriesE5EC
Output signalRelay (6)
Supply voltage24 VAC/DC
IP ratingIP66
ProtocolRS-485 (CompoWay/F, Modbus)
MountingPanel Mount
Temp operating max55 °C
Temp operating min-10 °C
Weight0.463 lb (210.01 g)
PackageBulk
Control methodOn/Off, Proportional (PID)

Product details

Six relay outputs and universal input

The E5EC-PR4D5M-014 accepts RTD and 13 thermocouple types plus 0–20 mA or 0–10 VDC process signals, covering a span from -200°C to 2300°C. That means one controller handles both temperature loops and analog process inputs — no separate signal conditioner needed. Six relay outputs give you headroom for a heat/cool pair, a process alarm, and two spare contacts — enough for a dual-loop or cascade configuration without an external relay expander.

RS-485 with Modbus and event input

RS-485 supports both CompoWay/F and Modbus protocols, so it drops into existing PLC or SCADA networks without a protocol gateway. The event input lets a remote dry contact latch the output, switch setpoints, or reset alarms — useful for a safety interlock or recipe change. Control method is selectable between on/off and full PID with autotune, so the same part works for simple tank level or a precision oven profile.

Panel fit and washdown rating

Panel cutout is 92.00 mm x 45.00 mm — the standard 1/8 DIN footprint. Screw terminals mean no special crimp tooling on the line. IP66 on the front panel means it survives hose-down cleaning in food, pharma, or washdown areas. Supply voltage is 24 VAC/DC, matching the common control transformer or DC bus in most panels. Operating range is -10°C to 55°C, fine for an unventilated cabinet as long as it's not right above a heat source.

MPN
E5EC-PR4D5M-014
