Panasonic Industrial AFP0RF32MP — PLC I/O & Expansion Modules

Panasonic AFP0RF32MP FP0R PLC, 16 In 16 Out, 32K Words, RS-4

MPNAFP0RF32MP
Active

Panasonic FP0R series, AFP0RF32MP, control logic, 16 digital inputs, 16 mixed outputs, 24 VDC, RS-485, 32K words memory, DIN rail mount.

$412.00Ref. price · indicative, final on quote
Panasonic Industrial AFP0RF32MP datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

AFP0RF32MP — Identification
ParameterValue
SeriesFP0R
AFP0RF32MP — I/O
ParameterValue
Inputs (count and type)16 - Digital
Outputs (count and type)16 - Pulse (4), PWM (4), Solid State (8)
AFP0RF32MP — Environmental
ParameterValue
Operating temperature range0°C~55°C
AFP0RF32MP — Mechanical
ParameterValue
Mounting typeDIN Rail
AFP0RF32MP — Approvals
ParameterValue
Approvals / certificationsCE, cULus
AFP0RF32MP — Other specifications
ParameterValue
SoftwareFPWINPRO7
Expandable3 Modules Max
Memory size32K Words
Display typeNo Display
CommunicationsRS-485
Supply voltage24VDC

Product details

The Panasonic AFP0RF32MP is a standalone CPU module in the FP0R series, running FPWINPRO7 for programming. It offers 16 digital inputs and 16 outputs split across four pulse, four PWM, and eight solid-state channels — enough to run a positioning axis or LED dimmer without an extra motion module. Memory is 32K words, expandable with up to three additional I/O or communication modules on the side bus. RS-485 onboard handles Modbus RTU or proprietary links; supply is 24 VDC. CE and cULus approvals are listed.

DIN-rail mount, 24 VDC supply. 16 digital inputs, 16 outputs (4 pulse, 4 PWM, 8 solid-state), expandable to 3 modules, 0°C–55°C ambient.

Frequently asked questions

Will the AFP0RF32MP drop into a panel specified around the AFP0RF32MT?

Yes, the AFP0RF32MP and AFP0RF32MT are spec-identical, so they are interchangeable without rewiring or software changes.

What series does the AFP0RF32MP belong to?

The AFP0RF32MP is part of the Panasonic FP0R series.

What compliance documentation is available for the AFP0RF32MP?

The module carries CE and cULus approvals. RoHS and REACH compliance is standard for Panasonic industrial controls; request the declaration when ordering.
