Red Lion Controls LD4T06P0
MPNLD4T06P0
Active
RELAY TIME DELAY 5A 120V CHASSIS
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | LDT |
| Function type | Time Meter |
| Terminal connection type | Internal Removable Terminal Blocks |
| Digital display screen type | LED |
| Supply voltage | 50 V AC – 250 V AC |
| AC voltage input | 50 V AC – 250 V AC |
| AC supply voltage | 50 V AC – 250 V AC |
| DC supply voltage | 21.6 V DC – 250 V DC |
| AC voltage supply max. | 250 V AC |
| AC voltage supply min. | 50 V AC |
| DC voltage supply max. | 250 V DC |
| DC voltage supply min. | 21.6 V DC |
All specifications
| Parameter | Value |
|---|---|
| DC voltage input signal | 21.6 V DC – 250 V DC |
| NEMA enclosure rating | 4X |
| Interface | RS-232RS-485 |
| Overall depth | 2.28 in |
| Overall width | 7.78 in |
| Overall height | 25.98 in |
| Digital display screen color | Red |
| Standards | CE; EN 61010-1; EN 61010-2-030; EN 61326-1; RoHS; UL |
| Brand | RED LION |
| Accuracy | +/-0.01% |
| Sub-brand | Carlton Bates Co |
| Display span | 0 to 999,999 |
| Parameters measured | AC VoltageDC Voltage |
| Display span - maximum | 999,999 |
| Display span - minimum | 0 |
| Number of display digits | 6 |
MPN
LD4T06P0
