Red Lion Controls PAXLPT00
MPNPAXLPT00
Active
COUNTER LED 6 CHAR 115/230V PNL
$342.07 – $526.22Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Series | PAX |
| Function type | Process Time Meter |
| Terminal connection type | Compression |
| Digital display screen type | LED |
| Supply voltage | 115 V AC – 230 V AC |
| AC voltage input | 115 V AC – 230 V AC |
| AC supply voltage | 115 V AC – 230 V AC |
| DC supply voltage | 10 V DC – 16 V DC |
| AC voltage supply max. | 230 V AC |
| AC voltage supply min. | 115 V AC |
| DC voltage supply max. | 16 V DC |
| DC voltage supply min. | 10 V DC |
All specifications
| Parameter | Value |
|---|---|
| DC voltage input signal | 10 V DC – 16 V DC |
| NEMA enclosure rating | 4X |
| Includes mounting hardware | Included |
| Cutout width | 1-31/32 in |
| Cutout height | 3-13/16 in |
| Overall depth | 4.2 in |
| Overall width | 1.95 in |
| Overall height | 1.95 in |
| Digit height - max. | 0.56 in |
| Digital display screen color | Red |
| Standards | CE; EN 61010-1; EN 61326-1; RoHS; UL |
| Brand | RED LION |
| Accuracy | +/-0.02% |
| Includes | Mounting Clip; Panel Gasket |
| Sub-brand | Carlton Bates Co |
| Display span | 999,999 |
| Cutout DIN size | 1/8 |
| Parameters measured | AC VoltageDC Voltage |
| Display span - minimum | 999,999 |
| Number of display digits | 6 |
MPN
PAXLPT00
