Schneider 140DDO35300 Servo Drives & Controls — now discontinued, supplied from remaining surplus and broker stock.
| Parameter | Value |
|---|---|
| Protection type | Internal output protection by 5 A fuse per group |
| Range of product | Modicon Quantum automation platform |
| Product or component type | Dc discrete output module |
| Maximum voltage drop | <0.4 V 0.5 A |
| Output voltage limits | 19.2...30 V |
| Discrete output voltage | 24 V DC |
| Surge current | 5 A 0.0005 s |
| Maximum load current | 16 A per module 4 A per group |
| Bus current requirement | 330 mA |
| Maximum leakage current | 0.4 mA 30 V |
| Power dissipation | 1.75 W + (0.4 V x total module load current) |
| Response time | <= 1 ms at state 1 to state 0 |
| Parameter | Value |
|---|---|
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 16404.2 ft (5000 m) |
| Standards | UL 508 CSA C22.2 No 142 |
| Marking | CE |
| Category | US1PC2118155 |
| Module format | Standard |
| Load inductance | Inductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 50 Hz |
| Fault indication | Blown fuse Loss of field power |
| Local signalling | 1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 32 LEDs (green) for input status |
| Group of channels | 4 groups of 8 |
| Discrete output logic | Positive logic (source) |
| Addressing requirement | 2 output words |
| Associated fuse rating | 3 A each point 5 A per group |
| Discrete output number | 32 |
| Absolute maximum output | 56 V 1.3 s decaying pulse |
| Isolation between group | 500 Vrms DC for 1 minute |
| Isolation between channels and bus | 1780 Vrms DC for 1 minute |
| Ambient air temperature for storage | -40...185 °F (-40...85 °C) |
| Resistance to electromagnetic fields | 9.1 V/m (10 V/m) 80...2000 MHz IEC 801-3 |
| Ambient air temperature for operation | 32...140 °F (0...60 °C) |
| Resistance to electrostatic discharge | 4 kV contact IEC 801-2 8 kV on air IEC 801-2 |
The 140DDO35300 is a Modicon Quantum DC discrete output module providing 32 source outputs at 24 V DC, rated 16 A per module and 4 A per group, with a 1 ms response time from state 1 to state 0. Each group is protected by a 5 A fuse, and the module carries CE marking along with UL 508 and CSA C22.2 No 142 certifications.
