Schneider Electric 140DDO36400

Schneider Electric 140DDO36400

MPN140DDO36400
Obsolete

Discrete Output Module

$1,828.00 – $4,178.49Ref. price · indicative, final on quote
Schneider Electric 140DDO36400 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

140DDO36400 key specifications
ParameterValue
Range of productModicon Quantum automation platform
Product or component typeDc discrete output module
Maximum voltage drop<0.4 V 0.5 A
Output voltage limits19.2...30 V
Discrete output voltage24 V DC
Surge current2 A
Maximum load current<= 3.2 A each group
Bus current requirement250 mA
Maximum leakage current1 mA 24 V
Short-circuit protectionWith
Power dissipation7 W
Response time<= 0.1 ms at state 1 to state 0

All specifications

140DDO36400 additional specifications
ParameterValue
Relative humidity95 % without condensation
Operating altitude<= 16404.2 ft (5000 m)
StandardsCSA C22.2 No 142 UL 508
MarkingCE
CategoryUS1PC2118155
Module formatStandard
Load inductanceInductance(H) = 0.5/((current(A))² x (switching frequency(Hz))) 0.5...4 Hz
Fault indicationFault sensing Fault point Loss of field power Fault reporting
Local signalling1 LED (green) for bus communication is present (Active) 1 LED (red) for external fault detected (F) 96 LEDs (green) for input status
Group of channels6 groups of 16
Discrete output logicNegative logic (sink)
Addressing requirement6 output words
Discrete output number96
Output overload protectionWith
Isolation between channels and bus500 Vrms DC for 1 minute
Ambient air temperature for storage-40...185 °F (-40...85 °C)
Resistance to electromagnetic fields9.1 V/m (10 V/m) 80...2000 MHz IEC 801-3
Ambient air temperature for operation32...140 °F (0...60 °C)
Resistance to electrostatic discharge4 kV contact IEC 801-2 8 kV on air IEC 801-2
