circuit breaker Compact NR100 F - TMD - 16 A - 3 poles 3d

Add to RFQ

Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jun 2026

Specifications

29069 — Ratings
Parameter	Value
Rated current (In)	100 A at 40 °C
Poles configuration	3P
Breaking capacity	20 kA at 480 V AC 50/60 Hz conforming to NEMA AB1 HIC 35 kA at 240 V AC 50/60 Hz conforming to NEMA AB1 HIC 15 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 35 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Rated service breaking capacity (Ics)	15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 11.25 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 18.75 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 26.25 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Rated operational voltage (Ue)	500 V AC 50/60 Hz conforming to IEC 60947-2
Rated insulation voltage (Ui)	690 V AC 50/60 Hz conforming to IEC 60947-2
Rated impulse withstand voltage (Uimp)	6 kV conforming to IEC 60947-2
Network type (AC/DC)	AC
Network frequency	50/60 Hz
Utilisation category	Category A

29069 — Protection
Parameter	Value
Trip unit technology	Thermal-magnetic
Suitability for isolation	Yes conforming to IEC 60947-2
Electrical durability (cycles)	Category A: 10000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
Mechanical durability (cycles)	25000 cycles

29069 — Mechanical
Parameter	Value
Mounting support	Backplate
Mounting mode	Fixed
Control type	Toggle
Local signalling/indication	Positive contact indication
Width	105 mm
Height	161 mm
Depth	86 mm

29069 — Environmental
Parameter	Value
Operating ambient temperature	-25...70 °C
Storage ambient temperature	-50...85 °C
IP degree of protection	IP40 conforming to IEC 60529
Pollution degree	3 conforming to IEC 60529
