Schneider Electric BMENOC0311

BMENOC0311 Modicon M580 Ethernet Module, 3 RJ45 Ports

MPNBMENOC0311
Active

Schneider Electric Modicon M580 BMENOC0311 Ethernet communication module, 3 x RJ45 10/100 Mbit/s, embedded switch, advanced web server, FactoryCast configurable, internal rack power.

$868.68Ref. price · indicative, final on quote
Schneider Electric BMENOC0311 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

BMENOC0311 specifications
ParameterValue
Range of productModicon M580
Product or component typeCommunication module
Integrated connection type3 Ethernet RJ45 10/100 Mbit/s double shielded twisted pair
Current consumption900 mA 3.3 V DC for product version >= 14) 1800 mA 3.3 V DC for product version < 14)
IP degree of protectionIP20
Communication serviceBandwidth management FDR server SNMP network administrator Modbus TCP I/O Scanner and Messaging Ethernet/IP I/O Scanner and Messaging RSTP support Port mirroring Embedded multiport switch
SupplyInternal power supply via rack
MarkingCE
CategoryUS1PC3418160
Directives2014/35/EU - low voltage directive 2014/30/EU - electromagnetic compatibility
Web serverAdvanced
Web servicesFactoryCast configurable
Local signalling1 LED (green) for processor running (RUN) 1 LED (red) for processor or system fault (ERR) 1 LED (green/red) for ETH MS (Ethernet port configuration status) 1 LED (green/red) for Eth NS (Ethernet network status)
Transmission support mediumEthernet backplane
Ambient air temperature for operation32...140 °F (0...60 °C)

Product details

Rack-mount Ethernet head for M580 PAC

The BMENOC0311 is a communication module for the Modicon M580 platform, fitting directly into the rack and drawing its power from the backplane. Three RJ45 ports at 10/100 Mbit/s act as an embedded three-port managed switch, so you can daisy-chain control network segments without an external switch. Supports Modbus TCP I/O Scanner and Messaging, EtherNet/IP, FDR server, SNMP, and RSTP for ring topology. Current draw depends on firmware revision: 900 mA at 3.3 VDC for version ≥14, 1800 mA for older versions. Check the version stamp on the side label before finalizing power budget.

Lifecycle and compliance status

Active product with no announced end-of-life. CE marked; complies with Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. RoHS and REACH documentation available from Schneider’s product compliance portal.

Communication services onboard

Advanced web server hosts the embedded FactoryCast configuration interface. Bandwidth management, port mirroring, and SNMP network administrator functions are supported without additional hardware. FDR server enables simple device replacement via automatic firmware and configuration restore.

Integration notes

Mounts in any slot of an M580 main or extension rack. IP20 enclosure; ambient operating range 0–60 °C. Three RJ45 jacks on the front panel accept double-shielded twisted-pair patch cables. The web server and FactoryCast tools allow commissioning via browser without additional software.

Frequently asked questions

What is BMENOC0311's listed supply on this component line?

Internal power supply via rack; no external power module required.

What compliance documentation does this brand provide for BMENOC0311?

CE marked, compliant with Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. Schneider Electric provides RoHS and REACH declarations on request.
