The AC-1 resistive rating is 100 A, for switching heaters or lighting banks where the load current stays steady through the contact closure.
The coil is 220 V AC, 50/60 Hz.
Mounts on either a plate or DIN rail. Dimensions are 158 mm high by 120 mm wide by 132 mm deep — fits standard panel layouts. IP2X finger protection per IEC 60529 means it's touch-safe in an enclosed panel but not for open-panel washdown environments.
Mechanical robustness
Rated for vibration: 1.5 Gn open, 3 Gn closed across 5–300 Hz. Shock: 6 Gn open, 7 Gn closed for 11 ms. That's enough for most industrial machinery but not extreme mobile equipment.
