Schneider Electric LC1E3801Q5 — Contactors

LC1E3801Q5 Easy TeSys Contactor, 38A AC-3, 380VAC Coil, Obso

MPNLC1E3801Q5
Obsolete

Schneider Electric Easy TeSys Control contactor, LC1E3801Q5, 3P(3NO), AC-3/AC-3e ≤440V 38A, 380V AC 50Hz coil, 1NC auxiliary contact.

StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

Identification

LC1E3801Q5 — Identification
ParameterValue
Product / component typeContactor
Series / rangeEasy TeSys
ApplicationMotor control Resistive load

Ratings & Performance

LC1E3801Q5 — Ratings & Performance
ParameterValue
Rated operational voltage (Ue)Power circuit: 10 MOhm for control circuit
Utilisation categoryAC-3 AC-3e AC-1

Contacts & Poles

LC1E3801Q5 — Contacts & Poles
ParameterValue
Pole configuration3P

Environmental

LC1E3801Q5 — Environmental
ParameterValue
IP degree of protectionIP2X conforming to IEC 60529
Operating altitude3000 m without derating
Mechanical robustnessVibrations contactor open (1.5 Gn, 5...300 Hz) Vibrations contactor closed (3 Gn, 5...300 Hz) Shocks contactor closed (10 Gn for 11 ms) Shocks contactor open (6 Gn for 11 ms)
Protective treatment / pollution degreeTH (pollution degree 3) conforming to IEC 60068-2-30 test Db
Fire resistance850 °C conforming to IEC 60695-2-1

Approvals

LC1E3801Q5 — Approvals
ParameterValue
StandardsEN/IEC 60947-1 EN/IEC 60947-4-1 EN/IEC 60947-5-1 GB/T 14048.1 GB/T 14048.4 GB/T 14048.5 EN/IEC 60335-1:Clause 30.2 EN/IEC 60335-2-40:Annex JJ

Mechanical

LC1E3801Q5 — Mechanical
ParameterValue
Width56 mm
Height84 mm
Depth86 mm

Product details

The LC1E3801Q5 is a 3-pole contactor from the Easy TeSys Control range, rated 38 A in AC-3 duty at ≤440 V — that's the motor-switching rating, so it handles a 3-phase induction motor load up to that current. The coil is 380 V AC 50 Hz, and it carries one normally-closed auxiliary contact. It's designed for motor control and resistive load switching, with utilisation categories AC-3, AC-3e, and AC-1.

The AC-1 rating handles resistive loads at higher current, but for motor duty, AC-3 is the binding spec. The 380 V AC 50 Hz coil means it's for European-standard control circuits at that voltage; don't try it on 400 V or 415 V without checking the coil tolerance band. Operates at -5 to 55 °C ambient, stores at -60 to 80 °C.

Also meets EN/IEC 60335-1 Clause 30.2 and 60335-2-40 Annex JJ for appliance and HVAC applications.

Frequently asked questions

What are the key ratings for this contactor?

AC-3 motor-switching rating of 38 A at ≤440 V, with a 380 V AC 50 Hz coil. It has 3 poles (3 normally-open) and 1 normally-closed auxiliary contact.

What standards does the LC1E3801Q5 comply with?

It complies with EN/IEC 60947-1, 60947-4-1, 60947-5-1, GB/T 14048.1, 14048.4, 14048.5, and EN/IEC 60335-1 Clause 30.2 and 60335-2-40 Annex JJ. Fire resistance is 850 °C per IEC 60695-2-1.

How do I source this obsolete part?

Since it's obsolete, it's sourced to order through surplus and independent distributor channels. Submit an RFQ for availability and pricing — no factory lead time applies.
