The Schneider LC1G185KUEN is a TeSys Giga 3-pole contactor for motor switching and power control. It's rated for 90 kW at 400 V AC-3 and 110 kW at 690 V AC-3, with AC-4 capability at 90 kW on 400 V. The coil accepts 100-250 V AC or DC, built-in bidirectional peak limiting eliminates external suppression. Mechanical durability is 8 million cycles, and it carries 1 NO + 1 NC auxiliary contacts integrated. Power dissipation per pole is 20 W in AC-1 (Ith 305 A) and 6 W in AC-3 (Ith 185 A). The contactor is dark grey, sized 7.6 x 4.3 x 7.6 inches, and mounts on a plate with 35 mm pitch. Connection is via bolted lugs up to 185 mm², and control wiring uses push-in terminals for 0.2-2.5 mm². Standards compliance includes UL 60947-4-1, CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, and JIS C8201-4-1, plus IEC 60335-1 for appliance applications.
Schneider LC1G185KUEN TeSys Giga 3P Contactor, 100-250V Coil
MPNLC1G185KUEN
Active
Schneider Electric TeSys Giga LC1G185KUEN, 3-pole contactor, dark grey, 100-250 V AC/DC coil, motor power 90 kW at 400 V AC-3, 8 Mcycles mechanical durability.
$246.38Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →Specifications
| Parameter | Value |
|---|---|
| Range of product | TeSys Giga |
| Product or component type | Contactor |
| Coil voltage | 100...250 V AC 50/60 Hz 100...250 V DC |
| Voltage | 1000 V |
| Control circuit voltage limits | Operational: 0.8 Uc Min...1.1 Uc Max (at Drop-out: 0.1 Uc Max...0.45 Uc Min (at <140 °F (60 °C)) |
| [Ue] rated operational voltage | <= 460 V DC |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Icw] rated short-time withstand current | 1.5 kA - 10 s 0.92 kA - 30 s 0.74 kA - 1 min 0.5 kA - 3 min 0.4 kA - 10 min |
| Breaking capacity | 1610 A at 440 V |
| [Ie] rated operational current | 305 A (at 185 A (at <140 °F (60 °C)) at <= 440 V AC-3 |
| [Ith] conventional free air thermal current | 305 A (at 104 °F (40 °C)) |
| Motor power | 55 kW at 230 V AC 50/60 Hz (AC-3e) 90 kW at 400 V AC 50/60 Hz (AC-3e) 90 kW at 415 V AC 50/60 Hz (AC-3e) 110 kW at 440 V AC 50/60 Hz (AC-3e) 110 kW at 500 V AC 50/60 Hz (AC-3e) 110 kW at 690 V AC 50/60 Hz (AC-3e) 75 kW at 1000 V AC 50/60 Hz (AC-3e) 55 kW at 230 V AC 50/60 Hz (AC-3) 90 kW at 400 V AC 50/60 Hz (AC-3) 90 kW at 415 V AC 50/60 Hz (AC-3) 110 kW at 440 V AC 50/60 Hz (AC-3) 110 kW at 500 V AC 50/60 Hz (AC-3) 110 kW at 690 V AC 50/60 Hz (AC-3) 75 kW at 1000 V AC 50/60 Hz (AC-3) 55 kW at 230 V AC 50/60 Hz (AC-4) 90 kW at 400 V AC 50/60 Hz (AC-4) 90 kW at 415 V AC 50/60 Hz (AC-4) 100 kW at 440 V AC 50/60 Hz (AC-4) 110 kW at 500 V AC 50/60 Hz (AC-4) 110 kW at 690 V AC 50/60 Hz (AC-4) 75 kW at 1000 V AC 50/60 Hz (AC-4) |
All specifications
| Parameter | Value |
|---|---|
| Inrush power in | 380 W |
| Maximum horse power rating | 50 hp at 200/208 V 60 Hz 60 hp at 230/240 V 60 Hz 125 hp at 460/480 V 60 Hz 150 hp at 575/600 V 60 Hz |
| Power dissipation per pole | 20 W AC-1 - Ith 305 A 6 W AC-3 - Ith 185 A |
| Inrush power in VA (50/60 hz, AC) | 540 VA |
| Hold-in power consumption in | 7.8 W |
| Poles description | 3P |
| Pole contact composition | 3 NO |
| Utilisation category | AC-1 AC-3 AC-3e AC-4 AC-5a AC-5b AC-6a AC-6b AC-8a AC-8b DC-1 DC-3 DC-5 |
| IP degree of protection | IP2X front face with shrouds IEC 60529 IP2X front face with shrouds VDE 0106 |
| Mounting support | Plate |
| Connection pitch | 1.4 in (35 mm) |
| Connections - terminals | Power circuit: bar 2 - busbar cross section: 25 x 6 mm Power circuit: lugs-ring terminals 1 0.3 in² (185 mm²) Power circuit: bolted connection Control circuit: push-in 1 0.0003...0.004 in² (0.2...2.5 mm²) - cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.0004...0.004 in² (0.25...2.5 mm²) - cable stiffness: flexible with cable end Control circuit: push-in 2 0.0008...0.002 in² (0.5...1.0 mm²) with cable end Control circuit: push-in 0.001...0.004 in² (0.75...2.5 mm²) - cable stiffness: solid stranded without cable end Control circuit: push-in 0.001...0.004 in² (0.75...2.5 mm²) - cable stiffness: flexible with cable end |
| Color | Dark grey |
| Depth | 7.6 in (193 mm) |
| Width | 4.3 in (108 mm) |
| Height | 7.6 in (193 mm) |
| Mechanical durability | 8 Mcycles |
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 IEC 60335-1:Clause 30.2 IEC 60335-2-40:Annex JJ UL 60335-1 UL 60335-2-40:Annex JJ |
| Range | TeSys |
| Category | US10I1222329 |
| Operating time | 40...70 ms closing 15...50 ms opening |
| Coil technology | Built-in bidirectional peak limiting |
| Average impedance | 0.00017 Ohm |
| Device short name | LC1G |
| Tightening torque | 159.3 lbf.in (18 N.m) |
| Compatibility code | LC1G |
| Overvoltage category | III |
| Protective treatment | TH |
| Contactor application | Power switching Motor control |
| Mechanical robustness | Vibrations 5...300 Hz 2 gn contactor open Vibrations 5...300 Hz 4 gn contactor closed Shocks 10 gn 11 ms contactor open Shocks 15 gn 11 ms contactor closed |
| Associated fuse rating | 200 A aM at 160 A aM at 315 A gG at 300 A UL Type J at <= 600 V |
| Maximum operating rate | 600 cyc/h AC-3 600 cyc/h AC-3e 300 cyc/h AC-1 150 cyc/h AC-4 |
| Safety reliability level | B10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1 |
| Irms rated making capacity | 2310 A at 440 V |
| Auxiliary contact composition | 1 NO + 1 NC |
| Ambient air temperature for storage | -76...176 °F (-60...80 °C) |
| Ambient air temperature for operation | -13...140 °F (-25...60 °C) |
| Permissible ambient air temperature around the device | -40...158 °F (-40...70 °C) at Uc |
Product details
Frequently asked questions
What compliance documentation does this brand provide?
The contactor carries UL 60947-4-1, CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, IEC 60335-1, and JIS C8201-4-1 certifications. It is also rated for IEC 60335-2-40 Annex JJ for heat pump applications.
What is the color of the LC1G185KUEN?
Dark grey.
What is the depth of the LC1G185KUEN?
7.6 inches (193 mm).
What are the key ratings of the LC1G185KUEN?
Motor power: 90 kW at 400 V AC-3, 110 kW at 690 V AC-3, and 75 kW at 1000 V AC-3. Coil voltage: 100-250 V AC/DC. Mechanical durability: 8 Mcycles. Auxiliary contacts: 1 NO + 1 NC. It is a 3-pole contactor in the TeSys Giga range.
