Schneider Electric LC1G4004LSEA

Schneider LC1G4004LSEA TeSys Giga 4P Contactor, 200-500V

MPNLC1G4004LSEA
Active

Schneider Electric TeSys Giga 4-pole contactor LC1G4004LSEA, 200-500 V AC/DC coil, 4 NO power poles, 3480 A breaking at 440 V, IP2X.

Schneider Electric LC1G4004LSEA datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LC1G4004LSEA key specifications
ParameterValue
Range of productTeSys Giga
Product or component typeContactor
Coil voltage200...500 V AC 50/60 Hz 200...500 V DC
Voltage1000 V
Control circuit voltage limitsOperational: 0.8 Uc Min...1.1 Uc Max (at Drop-out: 0.1 Uc Max...0.45 Uc Min (at <140 °F (60 °C))
[Ue] rated operational voltage<= 460 V DC
[Uimp] rated impulse withstand voltage8 kV
[Icw] rated short-time withstand current3.6 kA - 10 s 2.4 kA - 30 s 1.7 kA - 1 min 1.2 kA - 3 min 1.0 kA - 10 min
Breaking capacity3480 A at 440 V
[Ie] rated operational current400 A (at 550 A (at <104 °F (40 °C)) at <= 1000 V AC-1
[Ith] conventional free air thermal current550 A (at 104 °F (40 °C))
Inrush power in300 W

All specifications

LC1G4004LSEA additional specifications
ParameterValue
Power dissipation per pole30 W AC-1 - Ith 550 A 16 W AC-3 - Ith 400 A
Inrush power in VA (50/60 hz, AC)535 VA
Hold-in power consumption in8.6 W
Poles description4P
Pole contact composition4 NO
Utilisation categoryAC-3 AC-3e AC-1 AC-5a AC-5b AC-6a AC-6b DC-1 DC-3 DC-5
IP degree of protectionIP2X front face with shrouds IEC 60529 IP2X front face with shrouds VDE 0106
Mounting supportPlate
Connection pitch1.8 in (45 mm)
Connections - terminalsPower circuit: bar 2 - busbar cross section: 32 x 10 mm Power circuit: lugs-ring terminals 1 0.3 in² (185 mm²) Power circuit: bolted connection Control circuit: push-in 1 0.0003...0.004 in² (0.2...2.5 mm²) - cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.0004...0.004 in² (0.25...2.5 mm²) - cable stiffness: flexible with cable end Control circuit: push-in 2 0.0008...0.002 in² (0.5...1.0 mm²) with cable end Control circuit: push-in 0.001...0.004 in² (0.75...2.5 mm²) - cable stiffness: solid stranded without cable end Control circuit: push-in 0.001...0.004 in² (0.75...2.5 mm²) - cable stiffness: flexible with cable end
ColorDark grey
Depth8.9 in (226 mm)
Width7.3 in (185 mm)
Height11.4 in (290 mm)
Mechanical durability8 Mcycles
StandardsEN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 UL 60335-1 UL 60335-2-40:Annex JJ
RangeTeSys
CategoryUS10I1222329
Operating time40...70 ms closing 15...50 ms opening
Coil technologyBuilt-in bidirectional peak limiting
Average impedance0.0001 Ohm
Device short nameLC1G
Tightening torque309.8 lbf.in (35 N.m)
Compatibility codeLC1G
Overvoltage categoryIII
Protective treatmentTH
Contactor applicationPower switching
Mechanical robustnessVibrations 5...300 Hz 2 gn contactor open Vibrations 5...300 Hz 4 gn contactor closed Shocks 10 gn 11 ms contactor open Shocks 15 gn 11 ms contactor closed
Associated fuse rating500 A aM at 315 A aM at 630 A gG at 600 A UL Type L at <= 600 V
Maximum operating rate600 cyc/h AC-3 600 cyc/h AC-3e 300 cyc/h AC-1
Safety reliability levelB10d = 400000 cycles contactor with nominal load EN/ISO 13849-1 B10d = 3000000 cycles contactor with mechanical load EN/ISO 13849-1
Irms rated making capacity5090 A at 440 V
Auxiliary contact composition1 NO + 1 NC
Ambient air temperature for storage-76...176 °F (-60...80 °C)
Ambient air temperature for operation-13...140 °F (-25...60 °C)
Permissible ambient air temperature around the device-40...158 °F (-40...70 °C) at Uc

Product details

The LC1G4004LSEA is a 4-pole TeSys Giga contactor from Schneider Electric, built for power switching of motor and resistive loads. Rated breaking capacity 3480 A at 440 V, making capacity 5090 A at 440 V, suited for AC-3 duty up to 600 cycles/hour. This contactor carries 4 normally-open power poles and an auxiliary block of 1 NO + 1 NC. Utilization categories include AC-3, AC-3e, AC-1, DC-1, DC-3, and DC-5 for motor starting, resistive, and DC loads.

Overvoltage category III, protective treatment TH (tropicalized). Mechanical durability 8 Mcycles, with safety reliability B10d 400,000 cycles under nominal load per EN/ISO 13849-1.

Mounting & Connections

Plate mounted. Overall dimensions: 290 mm height, 185 mm width, 226 mm depth. Power terminals accept bars up to 32x10 mm or lugs up to 185 mm²; control circuit uses push-in terminals for 0.2-2.5 mm² solid/stranded or 0.25-2.5 mm² flexible with ferrule. Tightening torque for power connections 35 N·m. IP2X front face with shrouds per IEC 60529. Connection pitch 45 mm. Color dark grey.

Frequently asked questions

What is the listed color of the LC1G4004LSEA?

Dark grey.

What is the depth of the LC1G4004LSEA?

226 mm (8.9 inches).

What compliance documentation does Schneider provide for this part?

The LC1G4004LSEA complies with EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, and JIS C8201-4-1, among others. Overvoltage category III and protective treatment TH are specified.
