Schneider LC1G5004EHEA Iec Contactors — now discontinued. Supplied from remaining channel stock; full specifications, lifecycle and same-series options are below.
| Parameter | Value |
|---|---|
| Range of product | TeSys Giga |
| Product or component type | Contactor |
| Coil voltage | 48...130 V AC 50/60 Hz 48...130 V DC |
| Voltage | 1000 V |
| Control circuit voltage limits | Operational: 0.8 Uc Min...1.1 Uc Max (at Drop-out: 0.1 Uc Max...0.45 Uc Min (at <60 °C) |
| [Ue] rated operational voltage | <= 460 V DC |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Icw] rated short-time withstand current | 4.0 kA - 10 s 2.8 kA - 30 s 2.2 kA - 1 min 1.5 kA - 3 min 1.2 kA - 10 min |
| Breaking capacity | 4600 A at 440 V |
| [Ie] rated operational current | 500 A (at 700 A (at <40 °C) at <= 1000 V AC-1 |
| [Ith] conventional free air thermal current | 700 A (at 40 °C) |
| Motor power | 150 hp at 200/208 V 60 Hz 200 hp at 230/240 V 60 Hz 400 hp at 460/480 V 60 Hz 450 hp at 575/600 V 60 Hz |
| Parameter | Value |
|---|---|
| Inrush power in | 360 W |
| Power dissipation per pole | 40 W AC-1 - Ith 700 A 20 W AC-3 - Ith 500 A |
| Inrush power in VA (50/60 hz, AC) | 450 VA |
| Hold-in power consumption in | 8.3 W |
| Poles description | 4P |
| Pole contact composition | 4 NO |
| Utilisation category | AC-3 AC-3e AC-1 AC-5a AC-5b AC-6a AC-6b DC-1 DC-3 DC-5 |
| IP degree of protection | IP2X front face with shrouds conforming to IEC 60529 IP2X front face with shrouds conforming to VDE 0106 |
| Mounting support | Plate |
| Connection pitch | 45 mm |
| Connections - terminals | Power circuit: bar 2 - busbar cross section: 32 x 10 mm Power circuit: lugs-ring terminals 1 185 mm² Power circuit: bolted connection Control circuit: push-in 1 0.2...2.5 mm² - cable stiffness: solid stranded without cable end Control circuit: push-in 1 0.25...2.5 mm² - cable stiffness: flexible with cable end Control circuit: push-in 2 0.5...1.0 mm² with cable end Control circuit: push-in 0.75...2.5 mm² - cable stiffness: solid stranded without cable end Control circuit: push-in 0.75...2.5 mm² - cable stiffness: flexible with cable end |
| Depth | 226 mm |
| Width | 185 mm |
| Color | Dark grey |
| Height | 290 mm |
| Mechanical durability | 8 Mcycles |
| Standards | EN/IEC 60947-4-1 EN/IEC 60947-5-1 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 JIS C8201-5-1 UL 60335-1 UL 60335-2-40:Annex JJ |
| Range | TeSys |
| Operating time | 40...70 ms closing 15...50 ms opening |
| Coil technology | Built-in bidirectional peak limiting |
| Average impedance | 0.00008 Ohm |
| Device short name | LC1G |
| Tightening torque | 35 N.m |
| Compatibility code | LC1G |
| Overvoltage category | III |
| Protective treatment | TH |
| Contactor application | Power switching |
| Mechanical robustness | Vibrations 5...300 Hz 2 gn contactor open Vibrations 5...300 Hz 4 gn contactor closed Shocks 10 gn 11 ms contactor open Shocks 15 gn 11 ms contactor closed |
| Associated fuse rating | 500 A aM at 400 A aM at 800 A gG at 600 A UL Type L at <= 600 V |
| Maximum operating rate | 600 cyc/h AC-3 600 cyc/h AC-3e 300 cyc/h AC-1 |
| Safety reliability level | B10d = 400000 cycles contactor with nominal load conforming to EN/ISO 13849-1 B10d = 3000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1 |
| Irms rated making capacity | 5090 A at 440 V |
| Auxiliary contact composition | 1 NO + 1 NC |
| Ambient air temperature for storage | -60...80 °C |
| Ambient air temperature for operation | -25...60 °C |
| Permissible ambient air temperature around the device | -40...70 °C at Uc |
The LC1G5004EHEA is a Schneider TeSys Giga 4-pole IEC contactor, order code LC1G5004EHEA, rated for 500 A switching current with a 130 V coil and 460 V supply voltage. It mounts to a plate, carries an IP2X front face with shrouds, and is built for power switching applications.
The LC1G5004EHEA carries UL 60947-4-1 and CSA C22.2 No 60947-4-1 certifications for North American installations, with a breaking capacity (Icu) of 4.6 kA.
