Schneider Electric LC1K06015Q7 — Contactors

Schneider TeSys K LC1K06015Q7 Contactor, 6 A, 380-400 VAC Co

MPNLC1K06015Q7
Obsolete

Schneider Electric TeSys K contactor, 3P, AC-3/AC-4 rated 6 A, 380-400 VAC coil, 1 NC auxiliary contact.

Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

LC1K06015Q7 — Identification
ParameterValue
Product / component typeContactor
Series / rangeTeSys
ApplicationMotor control
LC1K06015Q7 — Ratings & Performance
ParameterValue
Utilisation categoryAC-3 AC-4
LC1K06015Q7 — Contacts & Poles
ParameterValue
Pole configuration3P
LC1K06015Q7 — Environmental
ParameterValue
Operating altitude2000 m without derating
LC1K06015Q7 — Other specifications
ParameterValue
Range of productTeSys K
Pole contact composition3 NO
[Ie] rated operational current6 A at 10 MOhm for signalling circuit

Product details

The LC1K06015Q7 is a TeSys K contactor from Schneider Electric, configured as a 3-pole normally open device with one normally closed auxiliary contact. It is rated for AC-3 and AC-4 utilisation categories at 6 A up to 440 V, with a 380-400 V AC coil. This is a motor-control contactor sized for small induction motors in the fractional-to-low horsepower range, typically found in conveyor drives, pump starters, or fan controls within a control panel.

AC-3 covers starting and stopping of squirrel-cage motors where the inrush can be 6-8 times the rated current. AC-4 adds plugging and inching duty — reversing or jogging — which stresses the contacts harder. This contactor is built for that cycle, but the 6 A figure is the continuous motor full-load current, not the break current.

That is a standard European industrial control voltage range. Operating altitude is 2000 m without derating, which covers most installations below that elevation. No IP rating is listed in the spec — this is an open-device contactor intended for enclosure mounting where the panel provides the environmental seal.

Frequently asked questions

What is the utilisation category of this contactor?

It is rated for AC-3 (motor starting) and AC-4 (plugging/inching) duty at 6 A up to 440 V.

What coil voltage does the LC1K06015Q7 use?

The coil is 380-400 V AC, 50/60 Hz.

How many poles and auxiliary contacts does it have?

It has 3 normally open main poles and 1 normally closed auxiliary contact.

MPN
LC1K06015Q7
