The Schneider Electric LC1K06016K7 is a TeSys K series 3-pole contactor rated for motor control in AC-3 and AC-3e duty at 6 A up to 440 V, with a 100 V AC standard coil and one normally closed auxiliary contact. It carries a 1.3 Mcycle electrical endurance at 6 A AC-3 and a 10 Mcycle mechanical life, with a maximum operating rate of 3600 cycles per hour. The contactor is certified to EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, and JIS C8201-4-1, making it accepted across European, North American, and Japanese installations.
Sourcing Reality — Obsolete, Sourced to Order
This part is officially obsolete per the manufacturer's lifecycle status.
The AC-3e rating extends the same capability for electronically controlled motor starts. The 100 V AC coil draws 30 VA inrush and 4.5 VA holding at 20 °C, so the control transformer sizing needs to handle the inrush peak, not just the sealed VA. With a 57 mm depth, 45 mm width, and 58 mm height, this contactor fits the standard TeSys K compact footprint for DIN-rail or panel-mount enclosures.
