The Schneider Electric TeSys LC1K06106FLS207 is a 3-pole contactor rated for motor control in AC-3 and AC-4 duty, with a 24 VDC coil that includes an integral suppression device. It switches loads up to 6 A in AC-3 category, which covers typical squirrel-cage motor starting and running — the rating that governs real-world fit for pumps, fans, and small conveyors. The coil holds in at 24 VDC nominal, with an operational range of 0.7 to 1.3 Uc and a drop-out threshold at or above 0.10 Uc below 50 °C. Inrush and hold-in power both sit at 1.8 W at 20 °C, so the thermal load on the control transformer is predictable — no hidden surge.
Rated for AC-3 and AC-4 utilization categories per EN/IEC 60947-4-1, UL 60947-4-1, and CSA C22.2 No 60947-4-1. The 6 A AC-3 rating at up to 440 V gives 1.3 million electrical cycles — enough for frequent starting in a packaging or material-handling line. Mechanical durability is 30 million cycles, so the contactor outlasts most machinery refreshes. Minimum switching capability is 5 mA at 17 V for the signalling circuit, which means it can reliably switch PLC-level dry-contact signals without welding or oxidation issues. The single normally-open auxiliary contact is instantaneous, rated for the same signalling circuit frequency up to 400 Hz. The contactor carries a B10d of 1,369,863 cycles at nominal load per EN/ISO 13849-1, making it usable in safety-related control systems where reliability data is required for the performance level calculation.
IP20 finger-safe protection per VDE 0106 means it can live in an open control cabinet without additional shrouding. Power connections use ring-lug terminals with a tightening torque of 0.8 to 1.3 N·m, accepting a 3.2 mm flat or Philips No 2 screwdriver.
