Schneider Electric LC1K0610V7 — Contactors

Schneider Electric LC1K0610V7 TeSys K Contactor, 3-Pole

MPNLC1K0610V7
Active

Schneider Electric TeSys K series, LC1K0610V7 contactor, 3-pole, 1 NO auxiliary contact, AC-3 / AC-4 duty, 6 A rated operational current, screw clamp terminals, DIN-rail mount.

$27.05 – $45.04Ref. price · indicative, final on quote
Schneider Electric LC1K0610V7 datasheet (PDF)
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

Identification

LC1K0610V7 — Identification
ParameterValue
Product / component typeContactor
Series / rangeTeSys
ApplicationMotor control

Ratings & Performance

LC1K0610V7 — Ratings & Performance
ParameterValue
Rated operational voltage (Ue)Power circuit Signalling circuit 10 MOhm for signalling circuit
Utilisation categoryAC-3 AC-3e AC-4

Contacts & Poles

LC1K0610V7 — Contacts & Poles
ParameterValue
Pole configuration3P

Environmental

LC1K0610V7 — Environmental
ParameterValue
IP degree of protectionIP2X VDE 0106
Operating altitude6561.68 ft (2000 m) without derating
Mechanical robustnessShocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Y axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on X axis6 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Z axis10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor opened2 Gn, 5...300 Hz IEC 60068-2-6
Protective treatment / pollution degreeTC IEC 60068 TC DIN 50016
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102

Approvals

LC1K0610V7 — Approvals
ParameterValue
StandardsEN/IEC 60947-4-1 GB/T 14048.4 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 IEC 60335-1:Clause 30.2 IEC 60335-2-40:Annex JJ UL 60335-2-40:Annex JJ

Mechanical

LC1K0610V7 — Mechanical
ParameterValue
Width1.8 in (45 mm)
Height2.3 in (58 mm)
Depth2.2 in (57 mm)

Product details

AC-3 rated current and electrical durability

The LC1K0610V7: For AC-4 applications (plugging, inching, reversing under load) the rating drops to 36 A at ≤440 V, with 50,000 cycles. Mechanical durability is 10 million cycles, so the electrical life under AC-3 is the limiting factor for most motor-control schedules.

Footprint is 2.2 in (57 mm) deep by 1.8 in (45 mm) wide by 2.3 in (58 mm) tall — a compact K-line body that snaps onto DIN rail or mounts on a plate. Screw-clamp terminals accept up to 4 mm² solid or 2.5 mm² flexible with ferrule, torqued to 0.8–1.3 N·m.

Standards and global compliance

Also listed for IEC 60335 family appliance standards and UL 60335-2-40. Flame retardance is V1 per UL 94, and meets NF F 16-101/102 class F2 for rail rolling stock.

Frequently asked questions

What is the LC1K0610V7 used for?

It is a 3-pole contactor for motor control in AC-3 duty (starting/running squirrel-cage motors) and AC-4 duty (plugging/inching).
