Schneider Electric LC1K1201K72 — Contactors

Schneider TeSys K LC1K1201K72 Contactor, 3P, 12A AC-3, 1NC A

MPNLC1K1201K72
Active

Schneider Electric TeSys K contactor, 3-pole, AC-3/AC-3e 12 A at 440 V, 1 NC auxiliary contact, 100 V AC coil with integral suppression device.

StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

Identification

LC1K1201K72 — Identification
ParameterValue
Product / component typeContactor
Series / rangeTeSys
ApplicationResistive load Motor control

Ratings & Performance

LC1K1201K72 — Ratings & Performance
ParameterValue
Rated operational voltage (Ue)Power circuit: Signalling circuit: 10 MOhm for signalling circuit
Utilisation categoryAC-3 AC-3e AC-1 AC-4

Contacts & Poles

LC1K1201K72 — Contacts & Poles
ParameterValue
Pole configuration3P

Environmental

LC1K1201K72 — Environmental
ParameterValue
Operating altitude2000 m without derating
Mechanical robustnessShocks contactor closed, on X axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Y axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Z axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on X axis: 6 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on Y axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor opened, on Z axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 Vibrations contactor opened: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6
Protective treatment / pollution degreeTC conforming to IEC 60068 TC conforming to DIN 50016
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102

Approvals

LC1K1201K72 — Approvals
ParameterValue
StandardsEN/IEC 60947-4-1 GB/T 14048.4 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 IEC 60335-1:Clause 30.2 IEC 60335-2-40:Annex JJ UL 60335-2-40:Annex JJ

Mechanical

LC1K1201K72 — Mechanical
ParameterValue
Width45 mm
Height58 mm
Depth57 mm

Product details

It carries 12 A in AC-3 / AC-3e duty at 440 V — the rating that governs switching of standard induction motors — and handles 20 A in AC-1 (resistive) service. One normally-closed (NC) auxiliary contact is included on the front, rated for signalling circuits down to 5 mA and 17 V. That low-level switching capability means it can be wired directly into a PLC input without a separate interface relay.

Panel builders will appreciate the screw-clamp terminals that accept one or two conductors: solid up to 4 mm², flexible with ferrule up to 2.5 mm². The 1.3 W heat dissipation means it won't cook adjacent components in a crowded enclosure. Rated for operation up to 2000 m without derating, and the coil holds in from 0.8 to 1.15 Uc, dropping out at 0.2 Uc. That's a wide enough margin to ride through brownouts on a marginal line supply.

The contactor carries a full suite of global approvals: EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, and GB/T 14048.4. It also meets IEC 60335-1 Clause 30.2 and IEC 60335-2-40 Annex JJ for appliance applications. Flame retardance is V1 per UL 94.

Frequently asked questions

What are the key ratings for the LC1K1201K72?

It is a 3-pole contactor rated 12 A in AC-3 / AC-3e at 440 V, 20 A in AC-1, with a 100 V AC coil and one NC auxiliary contact. Mechanical durability is 10 million cycles.

What compliance documentation is available for this contactor?

It is certified to EN/IEC 60947-4-1, UL 60947-4-1, CSA C22.2 No 60947-4-1, JIS C8201-4-1, and GB/T 14048.4. Flame retardance is V1 per UL 94. The integral suppression device meets IEC 60335-1 and -2-40 requirements for appliance use.

MPN
LC1K1201K72
