Schneider Electric TeSys K series, LC1K1210N7TQ, 3-pole contactor, AC-3 12 A, coil 400/415 V AC.
| Parameter | Value |
|---|---|
| Product / component type | Contactor |
| Parameter | Value |
|---|---|
| Utilisation category | AC-1 AC-3 |
| Parameter | Value |
|---|---|
| Pole configuration | 3P |
| Parameter | Value |
|---|---|
| Flame retardance | Class C2 conforming to NF F 16-101 Class C2 conforming to NF F 16-102 V1 conforming to UL 94 |
| Parameter | Value |
|---|---|
| Width | 45 mm |
| Height | 58 mm |
| Depth | 57 mm |
| Parameter | Value |
|---|---|
| Coil technology | Without built-in bidirectional peak limiting diode suppressor |
| Range of product | TeSys K |
| Device short name | LC1K |
| Compatibility code | LC1K |
| Control circuit type | AC |
| Pole contact composition | 3 NO |
| [Ie] rated operational current | 12 A (at 20 A (at 10 MOhm for control circuit |
The Schneider TeSys K LC1K1210N7TQ is a 3-pole contactor rated 12 A in AC-3 utilisation category at 440 V, with a 400/415 V AC control coil.
At 45 mm wide, 57 mm deep, and 58 mm tall, this contactor fits the standard 45 mm modular envelope common in DIN-rail control panels. Flame retardance is rated V-1 per UL 94 and Class C2 per NF F 16-101/102, so it meets rail and industrial panel flammability requirements without an external barrier.
Width 45 mm, depth 57 mm, height 58 mm. It fits the standard 45 mm modular DIN-rail pitch.
It is rated for AC-1 (resistive) and AC-3 (squirrel-cage motor) duty. The 12 A rated operational current applies to AC-3 at 440 V.
It is rated V-1 per UL 94 and Class C2 per NF F 16-101 and NF F 16-102, suitable for rail and industrial panel applications.
