Schneider Electric LC1K1210P72 — Contactors

LC1K1210P72 TeSys K Contactor, 3P, 12 A AC-3, 230 V AC Coil

MPNLC1K1210P72
Active

Schneider Electric TeSys K contactor, LC1K1210P72, 3-pole, AC-3 ≤440 V 12 A, 1 NO auxiliary contact, 230 V AC coil.

Schneider Electric LC1K1210P72 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

LC1K1210P72 — Identification
ParameterValue
Product / component typeContactor
Series / rangeTeSys
ApplicationResistive load Motor control
LC1K1210P72 — Ratings & Performance
ParameterValue
Utilisation categoryAC-4 AC-1 AC-3 AC-3e
LC1K1210P72 — Contacts & Poles
ParameterValue
Pole configuration3P
LC1K1210P72 — Environmental
ParameterValue
Operating altitude2000 m without derating
LC1K1210P72 — Mechanical
ParameterValue
Width45 mm
Height58 mm
Depth57 mm
LC1K1210P72 — Other specifications
ParameterValue
Range of productTeSys K
Device short nameLC1K
Pole contact composition3 NO
[Ie] rated operational current20 A (at 12 A at 16 A (at 12 A at 10 MOhm for signalling circuit
Ambient air temperature for storage-50...80 °C

Product details

It carries an AC-3 rated operational current of 12 A at ≤440 V, with a 230 V AC coil.

The utilisation categories listed — AC-1 (resistive), AC-3 (squirrel-cage motor starting/running), AC-3e (high-efficiency motors), and AC-4 (plugging/inching) — tell you this contactor handles both steady-state and demanding motor duty. The 12 A AC-3 rating at ≤440 V is the one to match against your motor FLA; the AC-1 rating (20 A) is higher because resistive loads lack the inrush. The 3 NO main poles and single NO aux cover a straightforward three-phase motor circuit with one feedback signal. If you need more aux contacts, you'd add a side-mount block from the TeSys K range.

Physical integration

Storage temperature range of -50 to 80 °C covers most unheated warehouses.

Frequently asked questions

What is the closest alternative to LC1K1210P72 in the TeSys K family?

Within the TeSys K range, the LC1K1210P7 (same coil voltage, same 12 A AC-3 rating) differs only in the auxiliary contact count — the P72 has 1 NO, the P7 has 0 aux. If you need the aux, the P72 is the correct choice; if not, the P7 is functionally identical for the main poles.

What are the key ratings for LC1K1210P72?

AC-3 rated operational current 12 A at ≤440 V, AC-1 rated 20 A. Coil 230 V AC. 3 NO main poles, 1 NO auxiliary contact. Altitude 2000 m without derating. Storage temperature -50 to 80 °C.
