Schneider Electric LC2K0901U7

TeSys K LC2K0901U7 reversing contactor, 9A AC-3

MPNLC2K0901U7
Active

TeSys K reversing contactor, 3P, AC-3 9A ≤440V, 230-240 VAC coil, 1 NC, preassembled with reversing power busbar, IP20.

$170.09 – $198.69Ref. price · indicative, final on quote
Schneider Electric LC2K0901U7 datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

LC2K0901U7 key specifications
ParameterValue
Product or component typeReversing contactor
[Ue] rated operational voltagePower circuit 690 V AC 50/60 Hz Signalling circuit 10 MOhm for signalling circuit
Power pole contact composition3 NO
Poles description3P
Utilisation categoryAC-3 AC-3e AC-4 AC-1
IP degree of protectionIP20 VDE 0106
Operating altitude6561.68 ft (2000 m) without derating
Depth2.2 in (57 mm)
Width3.5 in (90 mm)
Height2.3 in (58 mm)
RangeTeSys
CategoryUS10I1222327

All specifications

LC2K0901U7 additional specifications
ParameterValue
Flame retardanceV1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102
Device short nameLC2K
Device applicationControl
Device presentationPreassembled with reversing power busbar
Protective treatmentTC IEC 60068 TC DIN 50016
Contactor applicationResistive load Motor control
Mechanical robustnessShocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Y axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on X axis6 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Y axis10 Gn for 11 ms IEC 60068-2-27 Shocks contactor opened, on Z axis10 Gn for 11 ms IEC 60068-2-27 Vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 Vibrations contactor opened2 Gn, 5...300 Hz IEC 60068-2-6
Ambient air temperature for storage-58...176 °F (-50...80 °C)
Ambient air temperature for operation-13...122 °F (-25...50 °C)

Product details

Reversing contactor, 9A AC-3, TeSys K frame

The LC2K0901U7 is a TeSys K reversing contactor – three poles, rated 9 A in AC-3 duty (≤440 V) for motor starting and reversing, plus AC-1 for resistive loads. Coil is 230–240 VAC.

Panel fit and wiring constraints

IP20 finger-safe – no extra shrouding required in ordinary enclosures. Ambient operating range –25 to +50 °C; storage –50 to +80 °C. Altitude 2000 m without derating. Preassembled reversing busbar means the mechanical interlock is already wired; you only bring in line and motor leads.

Active lifecycle – no phase-out or last-time-buy flagged. Available to order on RFQ.

Utilisation notes

Rated for AC-3, AC-3e, AC-4, and AC-1 – covers standard motor reversing (AC-3), high-inertia loads (AC-4), and resistive heating elements (AC-1). Mechanical robustness: 10 Gn shocks on closed contacts, 15 Gn on Y/Z axes under IEC 60068-2-27. Flame retardance meets V1, NF F 16-101, NF F 16-102.

Frequently asked questions

What is the depth of LC2K0901U7?

Listed depth is 2.2 in (57 mm).

What product range does LC2K0901U7 belong to?

It is part of the TeSys range, specifically the TeSys K series of contactors and starters.
