Schneider Electric LP1K09015BDTQ
MPNLP1K09015BDTQ
Active
set of 10 contactors, TeSys LP1-K, 3P, AC-3/AC-3e, 690V, 9A, coil 24V DC
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsListing updated Jun 2026
Specifications
Identification
| Parameter | Value |
|---|---|
| Product / component type | Contactor |
| Application | Motor control Resistive load |
Ratings & Performance
| Parameter | Value |
|---|---|
| Utilisation category | AC-3 AC-1 AC-3e |
Contacts & Poles
| Parameter | Value |
|---|---|
| Pole configuration | 3P |
Environmental
| Parameter | Value |
|---|---|
| IP degree of protection | IP2X VDE 0106 |
| Operating altitude | 6561.68 ft (2000 m) without derating |
| Protective treatment / pollution degree | TCIEC 60068 |
| Fire resistance | 1562 °F (850 °C) IEC 60695-2-1 |
Approvals
| Parameter | Value |
|---|---|
| Standards | EN/IEC 60947-4-1 GB/T 14048.4 UL 60947-4-1 CSA C22.2 No 60947-4-1 JIS C8201-4-1 |
Mechanical
| Parameter | Value |
|---|---|
| Width | 1.8 in (45 mm) |
| Height | 2.3 in (58 mm) |
| Depth | 2.2 in (57 mm) |
MPN
LP1K09015BDTQ
