The Schneider Electric LP1K09105JD3 is a TeSys K contactor — three poles, normally open, rated 9 A in AC-3 utilisation category at ≤440 V, with a 12 V DC coil. The AC-3 rating governs motor switching (starting and disconnecting under load), so this 9 A figure is the current it handles for typical induction motor duty. For resistive loads (AC-1) the rating is higher at 20 A, which is the current-carrying capacity without the arcing stress of motor inrush. The coil includes a built-in bidirectional peak limiting diode suppressor — no external flyback diode needed across the coil terminals. Hold-in power consumption is 3 W at 20 °C, with the same figure for inrush power. This matters for DC-supply budgeting in a panel with multiple contactors; each unit draws 3 W steady-state once picked.
Schneider TeSys K LP1K09105JD3 Contactor, 3P, 9A AC-3, 12V D
MPNLP1K09105JD3
Active
Schneider Electric TeSys K contactor, 3P, AC-3 ≤440V 9A, 1 NO aux, 12V DC coil, built-in diode suppression.
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| Product / component type | Contactor |
| Series / range | TeSys |
| Parameter | Value |
|---|---|
| Utilisation category | AC-1 AC-4 AC-3 |
| Parameter | Value |
|---|---|
| Pole configuration | 3P |
| Parameter | Value |
|---|---|
| Flame retardance | V1 conforming to UL 94 Requirement 2 conforming to NF F 16-101 Requirement 2 conforming to NF F 16-102 |
| Parameter | Value |
|---|---|
| Width | 45 mm |
| Height | 58 mm |
| Depth | 57 mm |
| Parameter | Value |
|---|---|
| Coil technology | Built-in bidirectional peak limiting diode suppressor |
| Range of product | TeSys K |
| Device short name | LP1K |
| Inrush power in | 3 W (at 20 °C) |
| Compatibility code | LP1K |
| Pole contact composition | 3 NO |
| Hold-in power consumption in | 3 W at 20 °C |
| [Ie] rated operational current | 20 A (at 9 A at 16 A (at 10 MOhm for signalling circuit |
Product details
Frequently asked questions
What are the key ratings for this contactor?
Rated operational current is 9 A in AC-3 (motor duty) at ≤440 V, and 20 A in AC-1 (resistive). Coil is 12 V DC with built-in diode suppression, consuming 3 W hold-in power. Three normally-open poles.
What compliance documentation does this part carry?
Flame retardance is V1 per UL 94, and it also complies with NF F 16-101 and NF F 16-102 Requirement 2 for rail-vehicle fire safety. The product range is Schneider TeSys K.
MPN
LP1K09105JD3
