Schneider Electric MGN61534

MGN61534 Multi9 C60H-DC 2P 30A DC MCB, 20 kA

MPNMGN61534
Active

Schneider Electric, Multi9 series, C60H-DC, MGN61534, 2-pole DC miniature circuit breaker, 30 A, C-curve, 20 kA breaking capacity at 220 VDC.

$27.94Ref. price · indicative, final on quote
Schneider Electric MGN61534 datasheet (PDF)
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

MGN61534 key specifications
ParameterValue
Control typeToggle
Network typeDC
Product or component typeMiniature circuit-breaker
Voltage500 V DC EN/IEC 60947-2
[Ue] rated operational voltage12...500 V DC
[Uimp] rated impulse withstand voltage6 kVEN/IEC 60947-2
Breaking capacity20 kA Icu 220 V DC GB 14048.2 10 kA Icu 440 V DC GB 14048.2 6 kA Icu 500 V DC GB 14048.2 20 kA Icu 220 V DC EN/IEC 60947-2 10 kA Icu 440 V DC EN/IEC 60947-2 6 kA Icu 500 V DC EN/IEC 60947-2 5 kA AIR 12...500 V DC UL 1077
Line rated current30 A 77 °F (25 °C)
[Ics] rated service breaking capacity4.5 kA 75 % GB 14048.2 - 500 V DC 7.5 kA 75 % GB 14048.2 - 440 V DC 15 kA 75 % GB 14048.2 - 220 V DC 15 kA 75 % EN/IEC 60947-2 - 220 V DC 7.5 kA 75 % EN/IEC 60947-2 - 440 V DC 4.5 kA 75 % EN/IEC 60947-2 - 500 V DC
Poles description2P
Number of protected poles2
Utilisation categoryCategory A EN/IEC 60947-2

All specifications

MGN61534 additional specifications
ParameterValue
IP degree of protectionIP20 conforming to IEC 60529 IP40 (modular enclosure) conforming to IEC 60529
Mounting modeClip-on
Mounting supportDIN rail
Wire stripping length0.6 in (14 mm) for top or bottom connection
Connections - terminalsTunnel type terminal top or bottom) 0.002...0.05 in² (1...35 mm²) AWG 18...AWG 2) - rigid stranded Tunnel type terminal top or bottom) 0.002...0.04 in² (1...25 mm²) AWG 18...AWG 4) - flexible Tunnel type terminal top or bottom) 0.002...0.04 in² (1...25 mm²) AWG 18...AWG 4) - flexible with ferrule Tunnel type terminal top or bottom) - 2 0.002...0.02 in² (1...16 mm²) AWG 18...AWG 6) - rigid stranded Tunnel type terminal top or bottom) - 2 0.002...0.02 in² (1...16 mm²) AWG 18...AWG 6) - flexible Tunnel type terminal top or bottom) - 2 0.002...0.02 in² (1...16 mm²) AWG 18...AWG 6) - flexible with ferrule Tunnel type terminal top or bottom) - 3 0.006 in² (4 mm²) AWG 6) - flexible stranded
Pollution degree3 EN/IEC 60947-2
Relative humidity95 % 131 °F (55 °C)
Operating altitude6561.68 ft (2000 m)
ColorGray
Depth2.9 in (73 mm)
Width1.4 in (36 mm)
Height3.2 in (81 mm)
Electrical durability3000 cycles L/R = 2 ms
Mechanical durability20000 cycles
StandardsUL 1077 GB 14048.2 EN/IEC 60947-2
RangeMulti9
CategoryUS10DE200915
Curve codeC
9 mm pitches4
Tropicalisation2 IEC 60068-2 2 GB 14048.2
Limitation class3 EN/IEC 60947-2
Local signallingON/OFF indication
Device short nameC60H-DC
Tightening torque31.0 lbf.in (3.5 N.m) top or bottom
Device applicationDistribution
Overvoltage categoryIV
Trip unit technologyThermal-magnetic
Magnetic tripping limit8.5 x In +/- 20 % AC
Earth-leakage protectionWithout
Provision for padlockingPadlockable
Suitability for isolationYes EN/IEC 60947-2
Contact position indicatorYes
Locking options descriptionIn position O
Ambient air temperature for storage-40...185 °F (-40...85 °C)
Ambient air temperature for operation-13...158 °F (-25...70 °C)
Comb busbar and distribution block compatibilityTop or bottom standard

Product details

2-pole DC breaker for dedicated DC distribution

The MGN61534 is a 2-pole DC miniature circuit breaker from Schneider Electric's Multi9 C60H-DC line, rated 30 A at 25 °C with a C-curve magnetic trip of 8.5 x In ±20%. Breaking capacity reaches 20 kA at 220 VDC, 10 kA at 440 VDC, and 6 kA at 500 VDC per IEC 60947-2; UL 1077 rating is 5 kA AIR across 12–500 VDC. Trip unit is thermal-magnetic, designed for DC networks with Category A utilisation and pollution degree 3.

Listed to UL 1077 and certified to EN/IEC 60947-2 and GB 14048.2, with IP20 finger-safe terminals and IP40 in an enclosure.

Mounting and termination

Provision for padlocking, ON/OFF indication on the toggle.

Frequently asked questions

What color is the MGN61534?

The housing is gray.

What is the depth of the MGN61534?

Depth is 2.9 in (73 mm).

What compliance documentation applies to the MGN61534?

It is listed under UL 1077, certified to EN/IEC 60947-2 and GB 14048.2, and includes tropicalisation per IEC 60068-2.

How do I source this part?

The MGN61534 is active and can be quoted to order. Submit an RFQ for current lead time and pricing.
