Schneider Electric TM171DWAL2U

TM171DWAL2U Modicon M171 Display Module, Obsolete, 12 VDC

MPNTM171DWAL2U
Obsolete

Schneider Electric Modicon M171 optimized wall thermostat display module, TM171DWAL2U, monochrome LCD, 4 keys, realtime clock, 12 VDC, CE, obsolete.

$94.73 – $166.59Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

TM171DWAL2U specifications
ParameterValue
Display typeLCD screen
Range of productModicon M171
Product or component typeDisplay module
Supply voltage12 V DC
Power consumption in5 W 0 W
IP degree of protectionIP40 front face:
ColorWhite
Depth1.2 in (31.3 mm)
Width3.8 in (96.5 mm)
Height5.4 in (137 mm)
Display colourMonochrome
SupplyExternal source
MarkingCE
CategoryUS1PC1222537
Number of key4
Realtime clockWith
Local signallingLCD display

Product details

What you're dealing with

The TM171DWAL2U is a Modicon M171 display module — white front face, monochrome LCD, four keys, a real-time clock onboard. Runs off 12 VDC from an external source, draws about 5 W, and carries CE marking. IP40 on the front face only, so it's panel-mount with protection from finger contact but not water jets.

What about an alternative?

No direct pin-compatible drop-in replacement surfaced in the records. If you're redesigning a panel, you'll want to look at current Modicon HMI or display products — but the form factor and 12 VDC supply might not translate straight across. Your best bet is to send the BOM requirements and we can cross-check against what's available on the surplus market.

Frequently asked questions

What is the closest official replacement for the TM171DWAL2U?

No official replacement order code is provided. Any alternative will require careful verification of fit, power, and interface.

What compliance markings does the TM171DWAL2U carry?

CE marked. No RoHS, REACH, or UL certifications are listed in the spec for this specific unit.

MPN
TM171DWAL2U
