Schneider Electric TM2-58LF42DT4LS0

Schneider TM2-58LF42DT4LS0 Modicon M258 Compact Base, 42 I/O, CANopen

MPNTM2-58LF42DT4LS0
Obsolete

Schneider TM2-58LF42DT4LS0 Industrial Computer Board — now discontinued. Supplied from remaining channel stock; full specifications, lifecycle and same-series options are below.

$3,579.98Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

TM2-58LF42DT4LS0 key specifications
ParameterValue
Range of productModicon M258
Voltage_in24 V
Voltage out24 V DC
Surge withstand0.5 kV differential mode EN/IEC 61000-4-5 1 kV common mode EN/IEC 61000-4-5
Current in4 mA fast input 4 mA regular input
Current out4 mA fast output
MountingSymmetrical DIN rail
Maximum cable distance between devices max<98.4 ft (30 m) regular input
Shock15 gn 11 ms
Altitude max0
Pollution degree2 IEC 60664
Humidity max5

All specifications

TM2-58LF42DT4LS0 additional specifications
ParameterValue
Depth83.82
Width238.76
Height99.06
StandardsUL 508 CSA C22.2 No 142 CSA C22.2 No 213 IEC 61131-2
MarkingCE
IP ratingIP20IEC 61131-2
Input_typeCurrent 0...20 mA Current 4...20 mA Voltage +/- 10 V
Package_typePCE
Channels500 Vrms AC
Data backed upVariables of type retain and retain persistent CR2477M Renata, 1.5 years
Realtime clockWithout any user calibration clock, clock drift < 30 s/month at 77 °F (25 °C) With user calibration clock, clock drift <= 6 s/month
Resistance1 gn 8.4...150 Hz DIN rail 3.5 mm 5...8.4 Hz DIN rail
Voltage15
Local signalling1 LED per channel I/O state 1 LED CAN0 STS 1 LED MBS COM 1 LED green/red APP0 1 LED green/red APP1 1 LED green/red Eth NS (Ethernet network status) 1 LED green/red Eth ST (Ethernet status) 1 LED green/red RUN/MS (module status) 1 LED green/red USB host 1 LED green/yellow Eth LA (Ethernet activity) 1 LED red BATT (battery status)
Supply voltage24
Software functionApplicatives functions blocks
Transmission rate125 kbit/s 1640.4 ft (500 m) CANopen 250 kbit/s 820.2 ft (250 m) CANopen 50 kbit/s 3280.8 ft (1000 m) CANopen 500 kbit/s 328.08 ft (100 m) CANopen 10 kbit/s 16404.2 ft (5000 m) CANopen 1000 kbit/s 13.1 ft (4 m) CANopen 20 kbit/s 8202.10 ft (2500 m) CANopen 800 kbit/s 82.02 ft (25 m) CANopen
Memory descriptionFlash 128 MB Internal RAM 64 MB
Display_resolution12 bits
Discrete i (O number)42
Input impedance6 kOhm fast input 6 kOhm regular input
Power consumption14.14
Switching current0.04
Storage temperature-13...158 °F (-25...70 °C)
Discrete_input_logicSink fast input Sink regular input Source input
Analogue input number4
Anti bounce filtering2 µs...4 ms configurable fast input/regular input and fast output
Counting input number8200 kHz
Discrete input number10 fast input 12 input 4 regular input
Discrete_output_logicSource
Discrete output number12 output 4 fast output
Integrated_connection_type1 isolated serial link female RJ45 Modbus master/slave RTU/ASCII or character mode ASCII RS232/RS485 300...115200 bps 1 isolated serial link female RJ45 Ethernet Modbus TCP/IP slave 10BASE-T/100BASE-TX 1 isolated serial link mini B USB 480 Mbit/s 1 isolated serial link USB type A 480 Mbit/s 2 free slots PCI 1 CANopen male SUB-D 9 CANopen master
Configurable filtering time0 ms fast input/regular input and fast output 1.5 ms fast input/regular input and fast output 12 ms fast input/regular input and fast output 4 ms fast input/regular input and fast output
Product specific applicationFor solutions
Disturbance radiated (Conducted)CISPR 11
Execution time per instruction22 ns Boolean
Main_product_or_component_typeLogic controller
Operating temperature32
Ordering and shipping details (Category)22532-M258 PLC

Product details

Overview

The TM2-58LF42DT4LS0 is a Schneider Modicon M258 compact base controller, order code TM2-58LF42DT4LS0, with 42 discrete I/O and 4 analog inputs accepting 0-20 mA, 4-20 mA, or +/-10 V signals. Runs on 24 V DC, mounts on symmetrical DIN rail, and is rated IP20 per IEC 61131-2.

Communication & Memory

CANopen interface supports selectable transmission rates from 10 kbit/s to 1 Mbit/s, with cable lengths from 4 m to 5000 m depending on the baud rate. On-board memory includes 128 MB flash and 64 MB internal RAM; analog inputs sample at 12-bit resolution.

Compliance

Carries CE marking and is certified to UL 508, CSA C22.2 No 142, CSA C22.2 No 213, and IEC 61131-2.

Lifecycle

MPN
TM2-58LF42DT4LS0
