Schneider TM3XFHSC202G HSC Module, 200 kHz, 24 V DC

Q: What is the depth of the TM3XFHSC202G?

Listed depth is 3.3 inches (85 mm). Width is 1.5 inches (39 mm), height is 3.5 inches (90 mm).

Q: What reset type does the TM3XFHSC202G have?

The module features automatic reset by default.

Q: What compliance standards does the TM3XFHSC202G meet?

It is listed under UL 508, CSA C22.2 No 142, CSA C22.2 No 213, ANSI/ISA 12-12-01, and EN/IEC 61131-2:2007.

Specifications

TM3XFHSC202G key specifications
Parameter	Value
Range of product	Modicon TM3
Output protection type	Against overload and short-circuits
Electrical circuit type	Standard input Latch input
Product or component type	Module hight speed counting
Output voltage	24 V DC transistor output
DC supply voltage	24 V
Output voltage limits	30 V DC
Discrete input voltage	24 V DC
Supply voltage	24 V DC external supply - 15...20 %)
Current consumption	100 mA 5 V DC 50 mA 24 V DC
Discrete output current	300 mA fast output Q0...Q7)
Counting frequency	200 kHz

All specifications

TM3XFHSC202G additional specifications
Parameter	Value
IP degree of protection	IP20 with protective cover in place
Mounting support	Top hat type TH35-15 rail IEC 60715 Top hat type TH35-7.5 rail IEC 60715 plate or panel with fixing kit
Pollution degree	2
Shock resistance	15 gn 11 ms
Storage altitude	0...9842.5 ft (0...3000 m)
Relative humidity	10...95 %, without condensation in operation) 10...95 %, without condensation in storage)
Operating altitude	0...6561.68 ft (0...2000 m)
Vibration resistance	3.5 mm 2...8.4 Hz DIN rail 1 gn 8.4...200 Hz DIN rail 3.5 mm 2...8.4 Hz panel 1 gn 8.4...200 Hz panel
Depth	3.3 in (85 mm)
Width	1.5 in (39 mm)
Height	3.5 in (90 mm)
Standards	CSA C22.2 No 142 ANSI/ISA 12-12-01 UL 1604 CSA C22.2 No 213 EN/IEC 61131-2:2007 UL 508
Reset	Automatic reset
Category	US10MSX22533
Services	HSC simple One shot/Modulo HSC main single phase One shot/Modulo/Event counting HSC main dual phase Modulo/Free-large Period meter Edge to Edge, Edge to Opposite
Counting mode	2 main expert function (main counting function, frequency meter, period meter) Max 8 simple counting function
Event management	8 maximum per PLC Thresholds < 10 µs
Local signalling	1 LED I/O 1 LED RUN 1 LED ERR
Discrete i (O number)	18
Discrete input logic	Sink or source
Discrete output logic	Source
Electromagnetic emission	Conducted emissions 120...69 dBµV/m QP10...150 kHz EN/IEC 55011 Conducted emissions 63 dBμV/m QP1.5...30 MHz EN/IEC 55011 Radiated emissions 40 dBµV/m class A30...230 MHz EN/IEC 55011 Conducted emissions 79...63 dBμV/m QP150...1500 kHz EN/IEC 55011 Radiated emissions 47 dBµV/m class A230...1000 MHz EN/IEC 55011
Number of input channels	10
Number of output channels	8
Resistance to fast transients	2 kV alimentation cableEN/IEC 61000-4-4 1 kV Ethernet lineEN/IEC 61000-4-4 1 kV serial linkEN/IEC 61000-4-4 1 kV inputEN/IEC 61000-4-4 1 kV transistor outputEN/IEC 61000-4-4
Ambient air temperature for storage	-40...185 °F (-40...85 °C)
Resistance to conducted disturbances	10 V 0.15...80 MHz EN/IEC 61000-4-4
Resistance to electromagnetic fields	9.1 V/m (10 V/m) 80 MHz...1 GHz EN/IEC 61000-4-3 2.7 V/m (3 V/m) 1.4 GHz...2 GHz EN/IEC 61000-4-3 0.9 V/m (1 V/m) 2 GHz...3 GHz EN/IEC 61000-4-3
Ambient air temperature for operation	-4...140 °F (-20...60 °C) horizontal installation -4...122 °F (-20...50 °C) vertical installation
Resistance to electrostatic discharge	8 kV in air EN/IEC 61000-4-2 4 kV on contact EN/IEC 61000-4-2

Product details

The Schneider Modicon TM3XFHSC202G is the high-speed counting module for the TM3 I/O expansion system, handling counts up to 200 kHz on its 10 sink/source inputs with automatic reset.

Counting and Event Capabilities

Two main expert counting functions support frequency meter or period meter modes, plus up to 8 simple counting channels. Event management triggers thresholds with response under 10 µs, and latch inputs accept fast pulses at the full 200 kHz rate. The 8 transistor outputs are source-logic, each rated 300 mA on Q0…Q7, with overload and short-circuit protection. Output voltage is 24 V DC, limited to 30 V DC maximum. Power draw is 100 mA from 5 V DC backplane and 50 mA from 24 V DC external supply. Supply voltage tolerance is -15% to +20% of 24 V DC.

Mounting and Environmental Compliance

The TM3XFHSC202G snaps onto TH35-7.5 or TH35-15 DIN rail (IEC 60715) or mounts on a plate/panel with the fixing kit. With the protective cover fitted, IP20 is maintained. Rated for pollution degree 2 environments. Storage temperature spans -40…85 °C; operating altitude is 0…2000 m, storage altitude to 3000 m. Vibration and shock resistance follow EN/IEC 61131-2:2007. Listed under UL 508, CSA C22.2 No 142, CSA C22.2 No 213, ANSI/ISA 12-12-01, and EN/IEC 61131-2:2007. Electromagnetic emissions meet EN/IEC 55011 Class A for conducted and radiated ranges.
