Schneider TM5SPS2F Modicon TM5 power distribution module, 1.136 A, 24 V DC

MPNTM5SPS2F
Active

Schneider TM5SPS2F Power Distribution Units.

$80.01 – $224.00Ref. price · indicative, final on quote
Schneider Electric TM5SPS2F datasheet (PDF)
StockContact for availability
MOQ1 pcs
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Jul 2026
How we verify every order →

Specifications

TM5SPS2F key specifications
ParameterValue
Range of productModicon TM5
Product or component typePower distribution module with internal fuse
Supply voltage24 V DC
Input current1136 mA TM5 power bus 740 mA TM5 power bus 6300 mA I/O power segment
Short-circuit protection6.3 A
Power supply output current1136 mA TM5 power bus 740 mA TM5 power bus 6.3 A I/O power segment
Typical current consumption34 mA 24 V DC
Maximum power dissipation in2.13 W
IP degree of protectionIP20
Electrical connectionScrew/spring terminal block
Pollution degree2
Shock resistance15 gn 11 ms

All specifications

TM5SPS2F additional specifications
ParameterValue
Relative humidity5...95 % without condensation
Operating altitude0...6561.68 ft (0...2000 m)
Vibration resistance1 gn 8.4...150 Hz) on DIN rail 3.5 mm 5...8.4 Hz) on DIN rail
Depth3.0 in (75 mm)
Width0.5 in (12.5 mm)
Height3.9 in (99 mm)
Housing colourGrey
StandardsIEC 61131-2 UL 508 CSA C22.2 No 213 CSA C22.2 No 142
MarkingCE
CategoryUS1PC1222532
Ambient air temperature for storage-13...158 °F (-25...70 °C)
Ambient air temperature for operation14...131 °F (-10...55 °C) without derating horizontal installation) 131...140 °F (55...60 °C) with derating factor horizontal installation) 14...122 °F (-10...50 °C) vertical installation)

Product details

Overview

The TM5SPS2F is a Modicon TM5 power distribution module with an internal fuse, rated 1.136 A input and output on a 24 V DC supply, designed to feed 24 V DC I/O modules and the TM5 bus. It mounts on a DIN rail, measures 12.7 x 99.06 x 76.2 mm, and carries IP20 protection with a grey housing. Shock rated at 15 gn for 11 ms.

Sizing and selection

Compared to the TM5SPS1F, which delivers 6.3 A in/out, the TM5SPS2F is limited to 1.136 A — choose the TM5SPS1F when the I/O bank draws more than 1.136 A. Both include an internal fuse; the TM5SPS2F's fuse is rated 6.3 A short-circuit protection.

The TM5SPS2F is an active catalogue item. It carries CE, UL 508, CSA C22.2 No 213, and CSA C22.2 No 142 certifications, plus California Proposition 65 marking. Shock rating of 15 gn 11 ms is verified per IEC 61131-2.
