TM5SDM4DTRFS
Schneider Electric
IP20-40...158 °F (-40...70 °C)14...122 °F (-10...50 °C) vertical installation) 14...131 °F (-10...55 °C) horizontal installation)
Ref. price$805.00
Lead time on requestGet quote
Schneider Electric TM5S Series
32 variants · Schneider Electric
About the Schneider Electric TM5S Series
AO Ctrl is an independent, China-based distributor and sourcing agent for Schneider Electric TM5S Series components — the parts repair and maintenance teams source here when a machine is down or the line is no longer sold locally — with the physical condition of every unit stated up front. The Schneider Electric TM5S Series series groups 32 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Every variant in the range shares a common IP rating of IP20. Variants differ by depth, height and pollution degree, so you can match the exact depth your application requires using the selection guide below. All listed Schneider Electric TM5S Series part numbers are active and orderable.
Select a variant by
- Depth
- 2.4 in (60 mm) · 3.0 in (75 mm) · 75 mm
- Height
- 3.9 in (99 mm) · 4.0 in (101 mm) · 99 mm
- Pollution degree
- 2 · Pollution degree 2
- Temp operating max
- 50 °C · 55 °C · 60 °C
- Temp operating min
- -10 °C · 0 °C
- Width
- 0.5 in (12.5 mm) · 0.8 in (20 mm) · 1.0 in (25 mm) · 12.5 mm
- Main product or component type
- Analog input module · Analog output module · Counter module · Discrete I/O module · Discrete output module · Safety discrete I/O module
- Storage temperature
- -40...70 °C · -40...158 °F (-40...70 °C) · -25...70 °C · -13...158 °F (-25...70 °C)
Shared specifications
- IP rating
- IP20
Variant comparison
| Parameter | TM5SDM4DTRFS | TM5SDO2DTRFS | TM5SDM8DTS | TM5SDM8TBFS | TM5SE1MISC20005 | TM5SE1RS2 |
|---|---|---|---|---|---|---|
| Depth | 3.0 in (75 mm) | 3.0 in (75 mm) | 75 mm | 3.0 in (75 mm) | 3.0 in (75 mm) | 3.0 in (75 mm) |
| Height | 3.9 in (99 mm) | 3.9 in (99 mm) | 99 mm | 3.9 in (99 mm) | 3.9 in (99 mm) | 3.9 in (99 mm) |
| Pollution degree | 2 | 2 | 2 | 2 | Pollution degree 2 | 2 |
| Temp operating max | 50 °C | 50 °C | 60 °C | 50 °C | 55 °C | 55 °C |
| Temp operating min | -10 °C | 0 °C | -10 °C | 0 °C | 0 °C | 0 °C |
| Width | 1.0 in (25 mm) | 1.0 in (25 mm) | 12.5 mm | 1.0 in (25 mm) | 0.5 in (12.5 mm) | 0.5 in (12.5 mm) |
| Main product or component type | Safety discrete I/O module | Discrete output module | Discrete I/O module | Safety discrete I/O module | Counter module | — |
| Storage temperature | -40...158 °F (-40...70 °C) | -40...158 °F (-40...70 °C) | -40...70 °C | -40...158 °F (-40...70 °C) | -13...158 °F (-25...70 °C) | — |
Request a quote on any Schneider Electric TM5S Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
