The XS630B1PBL2 is an M30 shielded inductive proximity sensor from the XS6 series, delivering a PNP normally-closed output with a 15 mm sensing distance. Its IP68 and IP69K ratings make it suitable for high-pressure washdown in food, beverage, and pharmaceutical lines — applications where a standard IP67 sensor would fail.
Lifecycle and compliance
Listed as current production. Compliance markings include CE, CSA, UL Listed, and RoHS. The nickel-plated brass body and IP69K rating suit washdown environments that would degrade polybutylene (PBT) housed sensors.
Mounting and wiring
Standard M30 threaded barrel mounts into a 30 mm hole. The 2 m PVC-jacketed cable has three conductors: brown (V+), blue (V-), and black (load). An integral LED indicates target detection for alignment and diagnostics.
