XS630B1MBU20
Schneider Electric
240–480 V< 40 Hz8–20 mm
Ref. price$26.67
Lead time on requestGet quote
Schneider Electric XS630B Series
56 variants · Schneider Electric
About the Schneider Electric XS630B Series
The Schneider Electric XS630B Series series groups 56 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. Variants differ by IP rating, output circuit type and supply voltage, so you can match the exact IP rating your application requires using the selection guide below.
Select a variant by
- IP rating
- IP67 / IP69K · IP68 / IP69K
- Output circuit type
- AC/DC-Type · NPN · PNP
- Supply voltage
- 24-240 V AC ; 24-240 V DC · Not Rated ; 12-24 V DC · Not Rated ; 12-48 V DC
- Pin count
- 3 · 4
Variant comparison
| Parameter | XS630B1MBU20 | XS630B1MAL10 | XS630B1PBL2 | XS630B1MAU20 | XS630B1PBM12 | XS630B1PAM12 |
|---|---|---|---|---|---|---|
| IP rating | — | IP68 / IP69K | IP68 / IP69K | IP67 / IP69K | IP67 / IP69K | IP67 / IP69K |
| Output circuit type | — | AC/DC-Type | PNP | AC/DC-Type | PNP | PNP |
| Supply voltage | — | 24-240 V AC ; 24-240 V DC | Not Rated ; 12-48 V DC | 24-240 V AC ; 24-240 V DC | Not Rated ; 12-48 V DC | Not Rated ; 12-48 V DC |
| Pin count | — | — | — | 3 | 4 | 4 |
Request a quote on any Schneider Electric XS630B Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
