ATV320U40N4W
Schneider Electric
IP6670 °C-25 °C
Ref. price$775.97 – $1,828.35
Lead time on requestGet quote
Schneider Electric ATV320U Series
105 variants · Schneider Electric
About the Schneider Electric ATV320U Series
The Schneider Electric ATV320U Series series groups 105 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common main product or component type of Variable speed drive, operating position of Vertical +/- 10 degree and storage temperature of -13...158 °F (-25...70 °C). Variants differ by depth, height and IP rating, so you can match the exact depth your application requires using the selection guide below.
Select a variant by
- Depth
- 6.2 in (158.0 mm) · 7.008 in (178.0 mm) · 7.9 in (200 mm) · 9.3 in (235.0 mm)
- Height
- 7.2 in (184.0 mm) · 9.1 in (232.0 mm) · 13.4 in (340 mm)
- IP rating
- IP20 · IP65 · IP66
- Pollution degree
- 2 · 3
- Width
- 5.5 in (140 mm) · 5.9 in (150 mm) · 9.8 in (250 mm)
Shared specifications
- Main product or component type
- Variable speed drive
- Operating position
- Vertical +/- 10 degree
- Storage temperature
- -13...158 °F (-25...70 °C)
- Temp operating max
- 70 °C
- Temp operating min
- -25 °C
- Temp storage max
- 70 °C
- Temp storage min
- -25 °C
Variant comparison
| Parameter | ATV320U07N4WS | ATV320U22M2W | ATV320U40M3C | ATV320U22M2WS | ATV320U11N4WS | ATV320U15N4W |
|---|---|---|---|---|---|---|
| Depth | 7.9 in (200 mm) | 9.3 in (235.0 mm) | 6.2 in (158.0 mm) | 9.3 in (235.0 mm) | 7.9 in (200 mm) | 7.9 in (200 mm) |
| Height | 13.4 in (340 mm) | 13.4 in (340 mm) | 7.2 in (184.0 mm) | 13.4 in (340 mm) | 13.4 in (340 mm) | 13.4 in (340 mm) |
| IP rating | IP65 | IP66 | IP20 | IP65 | IP65 | IP66 |
| Pollution degree | 3 | 3 | 2 | 3 | 3 | 3 |
| Width | 9.8 in (250 mm) | 9.8 in (250 mm) | 5.5 in (140 mm) | 9.8 in (250 mm) | 9.8 in (250 mm) | 9.8 in (250 mm) |
Request a quote on any Schneider Electric ATV320U Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
