BSH1001M11A2A
IP50≥ 1000 Hz
Lead time on requestGet quote
Schneider Electric BSH100 Series
152 variants · Schneider Electric
Schneider Electric BSH100 Series — schneider
Schneider Electric BSH100 Series includes 152 variants for industrial automation. Standardized form factors for control panel integration in motor control, power distribution, and building infrastructure.
Applications
Control panels, machine building, building services.
Selection
Match specifications: rated current, voltage, poles, control voltage. Provide complete order code for pricing.
Availability
Standard in distributor stock. Custom options may require lead time.
About the Schneider Electric BSH100 Series
The Schneider Electric BSH100 Series series groups 152 related part numbers, each listed with full specifications, a datasheet where available, and an RFQ option. The listed variants share a common centring collar diameter of 3.7 in (95 mm), frequency of 8 kHz and main product or component type of Servo motor. Variants differ by feedback type, IP rating and length, so you can match the exact feedback type your application requires using the selection guide below. The range mixes active and legacy part numbers, so you can source both current Schneider Electric BSH100 Series variants and discontinued ones from a single page.
Select a variant by
- Feedback type
- Multiturn SinCos Hiperface · Single turn SinCos Hiperface
- IP rating
- IP50 · IP65 / IP67
- Length
- 6.6 in (168.5 mm) · 7.9 in (199.5 mm) · 8.05 in (204.5 mm) · 9.3 in (235.5 mm) · 10.7 in (271.5 mm) · 10.9 in (276.5 mm) · 12.1 in (307.5 mm)
- Shaft diameter
- 0.7 in (19 mm) · 0.9 in (24 mm)
- Shaft end type
- Keyed · Untapped
- Max radial force fr n
- 620 N 4000 rpm 690 N 3000 rpm 790 N 2000 rpm 990 N 1000 rpm · 1050 N 1000 rpm 660 N 4000 rpm 730 N 3000 rpm 830 N 2000 rpm · 1070 N 1000 rpm 740 N 3000 rpm 850 N 2000 rpm
Shared specifications
- Centring collar diameter
- 3.7 in (95 mm)
- Frequency
- 8 kHz
- Main product or component type
- Servo motor
- Max axial force fa n
- 0.2 x Fr
Variant comparison
| Parameter | BSH1001P12A1A | BSH1001T01F2A | BSH1002P31A1A | BSH1003P02F2A | BSH1003P12F2A | BSH1004P11F2A |
|---|---|---|---|---|---|---|
| Feedback type | Multiturn SinCos Hiperface | Single turn SinCos Hiperface | Single turn SinCos Hiperface | Multiturn SinCos Hiperface | Multiturn SinCos Hiperface | Single turn SinCos Hiperface |
| IP rating | IP50 | IP50 | IP65 / IP67 | IP50 | IP50 | IP50 |
| Length | 6.6 in (168.5 mm) | 7.9 in (199.5 mm) | 8.05 in (204.5 mm) | 10.7 in (271.5 mm) | 10.7 in (271.5 mm) | 12.1 in (307.5 mm) |
| Shaft diameter | 0.7 in (19 mm) | 0.7 in (19 mm) | 0.7 in (19 mm) | 0.7 in (19 mm) | 0.7 in (19 mm) | 0.9 in (24 mm) |
| Shaft end type | Keyed | Untapped | Keyed | Untapped | Keyed | Keyed |
| Max radial force fr n | — | — | 620 N 4000 rpm 690 N 3000 rpm 790 N 2000 rpm 990 N 1000 rpm | 1050 N 1000 rpm 660 N 4000 rpm 730 N 3000 rpm 830 N 2000 rpm | 1050 N 1000 rpm 660 N 4000 rpm 730 N 3000 rpm 830 N 2000 rpm | 1070 N 1000 rpm 740 N 3000 rpm 850 N 2000 rpm |
Request a quote on any Schneider Electric BSH100 Series part number and we confirm price, availability and lead time per line — including end-of-life and allocation-constrained variants.
