How do the Schneider Electric Schneider Electric LV481 Series variants differ?

Schneider Electric LV481 Series part numbers differ by main product or component type, depth, electrical life cycles and fuse type. Use the selection guide above to pick by main product or component type.

How many Schneider Electric Schneider Electric LV481 Series part numbers are listed?

12 Schneider Electric Schneider Electric LV481 Series part numbers are listed, each with specifications and a datasheet where available.

How do I get pricing and lead time for Schneider Electric Schneider Electric LV481 Series?

Request a quote (RFQ) for any Schneider Electric LV481 Series part number and we confirm price, availability and lead time per line — including end-of-life and hard-to-find variants.

Schneider Electric LV481 Series — Schneider Electric

Variant comparison

Parameter	LV481203	LV481464	LV481474	LV481514	LV481523	LV481524
Main product or component type	Cage terminal	Switch-disconnector-fuse	Switch-disconnector-fuse	Switch-disconnector-fuse	Switch-disconnector-fuse	Switch-disconnector-fuse
Depth	—	250 mm	289 mm	87 mm	116 mm	116 mm
Electrical life cycles	—	AC-22 A: 100 cycles 415 V AC 50/60 Hz AC-22 A: 100 cycles 690 V AC 50/60 Hz	AC-22 A: 100 cycles 415 V AC 50/60 Hz AC-22 A: 100 cycles 690 V AC 50/60 Hz AC-23 A: 100 cycles 415 V AC 50/60 Hz	AC-22 A: 1500 cycles 415 V AC 50/60 Hz AC-23 A: 1500 cycles 415 V AC 50/60 Hz AC-22 A: 1500 cycles 690 V AC 50/60 Hz AC-23 A: 1500 cycles 690 V AC 50/60 Hz	AC-22 A: 1000 cycles 415 V AC 50/60 Hz AC-23 A: 1000 cycles 415 V AC 50/60 Hz AC-22 A: 1000 cycles 690 V AC 50/60 Hz AC-23 A: 1000 cycles 690 V AC 50/60 Hz	AC-22 A: 1000 cycles 415 V AC 50/60 Hz AC-23 A: 1000 cycles 415 V AC 50/60 Hz AC-22 A: 1000 cycles 690 V AC 50/60 Hz AC-23 A: 1000 cycles 690 V AC 50/60 Hz
Fuse type	—	DIN	DIN	NFC	NFC	NFC
Height	—	300 mm	300 mm	118 mm	162 mm	162 mm
Mechanical life cycles	—	5000 cycles	5000 cycles	10000 cycles	10000 cycles	10000 cycles
Width	—	458 mm	562 mm	148 mm	148 mm	184 mm
