Siemens 3UG4631-1AW30

Siemens 3UG4631-1AW30 SIRIUS Voltage Monitoring Relay, 24-24

MPN 3UG4631-1AW30
NRND

Siemens SIRIUS 3UG4631-1AW30 voltage monitoring relay, 24-240 V AC/DC, overvoltage and undervoltage detection, LCD display, IP20, 22.5 mm wide.

Dispatch SLA24-48h Global Rush
Quality CheckOriginal Seal & Physical QC
IncotermsDAP / DDP Available
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & stockist· Listing updated Sep 2026

Specifications

3UG4631-1AW30 specifications
ParameterValue
IP ratingIP20
MountingSnap-on Mounting
Depth91 mm
Width22.5 mm
Height92 mm

Product details

The Siemens 3UG4631-1AW30 is a SIRIUS voltage monitoring relay — a DIN-rail-mount device that watches a single-phase AC or DC supply and trips its output contacts when the voltage strays outside a set window. It detects both overvoltage and undervoltage conditions, so it holds the unit on the grid only as long as the supply stays within the configured limits. Rated supply range is 24 to 240 V AC/DC at 50 or 60 Hz, which covers most industrial control voltages from 24 VDC panels up to 240 VAC motor control centers. The relay uses a digital setting via the LCD display — no trim pots to drift over a season of thermal cycling.

Key Ratings and Their Meaning for Fit

The 22.5 mm width and 92 mm height fit a standard single-module DIN-rail footprint; snap-on mounting means it clips into place without tools. Depth of 91 mm leaves clearance for wiring in a 120 mm deep enclosure — provided the gland plate isn't crowded directly behind it. Output contacts are rated 1 A at 24 V, 0.2 A at 125 V, and 0.1 A at 250 V — these are the switching limits for the relay's internal contacts. If the load exceeds these, an interposing contactor is required. The relative repeat accuracy of 1 % means the trip point won't wander more than 1 % of the set value over temperature and time.

No official successor has been published, and no second-source cross-reference exists in the Siemens documentation. The part is the current design; if a buyer needs a drop-in alternative, the only path is the same order code.

MPN
3UG4631-1AW30
