Fuji Electric FRN0.75E1S-4C — AC Drive (VFD) 480V

Fuji Electric FRN0.75E1S-4C FRENIC High Performance Inverter

MPNFRN0.75E1S-4C

Fuji Electric FRENIC Series High Performance Inverter, FRN0.75E1S-4C, 0.75 kW, 3-phase 400 V, Standard IP20 enclosure.

$397.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

FRN0.75E1S-4C — Specifications
ParameterValue
Weight0.8 Kg
EnclosureS : Standard (IP20)
ApplicableE : High performance/Compact
Series nameFRN : FRENIC series
Product typeFRENIC Series High Performance Inverter
Development code1
Power supply voltage4 : Three-phase 400 V
Nominal applied motor0.75 : 0.75 kW

Product details

The FRN0.75E1S-4C is a Fuji Electric FRENIC Series high performance inverter sized for a 0.75 kW three-phase induction motor on a 400 V supply. The 'E' in the order code marks it as the high-performance/compact variant of the FRENIC family, suited for applications requiring tighter speed regulation or torque control than a general-purpose drive delivers.

No second-source cross-reference exists within the FRENIC family at this exact power and voltage point — the order code defines the variant.

The 0.75 kW nominal applied motor rating defines the maximum continuous motor load this drive can handle under normal duty. For a 400 V three-phase supply, that corresponds to roughly 2.2 A output current — the drive is sized for small pumps, fans, conveyors, or spindle motors in that power class. The IP20 enclosure is the standard industrial cabinet-mount variant.

Frequently asked questions

What enclosure rating does FRN0.75E1S-4C have?

It has a Standard IP20 enclosure (code 'S' in the order code). This is for indoor cabinet mounting only, not for washdown or outdoor use.

MPN
FRN0.75E1S-4C
