The Fuji Electric FRN0005G2S-2GU is a FRENIC-MEGA series drive rated for 1 hp (0.75 kW) output at 8 A continuous, accepting 200 to 240V AC single- or three-phase input. The NEMA 1 open enclosure suits panel-mount installations where drip protection is needed but full washdown is not. Output frequency range of 25 to 500 Hz covers standard induction motors and higher-speed spindle applications. The built-in Ethernet port supports networked control without an external comms module.
Integration Notes
The drive includes 9 digital inputs, 6 digital outputs, 3 analog inputs, and 2 analog outputs — sufficient for basic speed control, run/stop, and feedback loops. Starting torque is 200% at 1 Hz, useful for high-inertia loads or breakaway torque applications. Acceleration and deceleration times are independently programmable from 0 to 6,000 seconds. No brake chopper or dynamic braking resistor is included internally; plan for an external braking module if overhauling loads are present.
