The Fuji Electric FRN0025F2S-4C is a FRENIC Series high performance inverter, designed for three-phase 400 V motor control. The 0025 in the order code indicates a 25 A rating, which sizes it for a 3-phase induction motor in the 7.5 kW to 11 kW range depending on duty cycle and ambient conditions. The S enclosure suffix means basic type with IP20 protection on the enclosure body and IP00 on the heat sink fins — standard for panel-mount installations where the drive is inside a cabinet. It keeps dust and incidental contact out of the electronics while relying on the panel's own IP rating for washdown or wet environments.
Integration Note
Three-phase 400 V input means it connects directly to a standard European or Asian industrial mains supply without a step-down transformer. The 25 A rating governs the input breaker sizing and cable cross-section — expect a 6 mm² supply cable for runs under 50 m. Mount the drive on a grounded metal backplate; the IP00 heat sink requires free air circulation above and below.
