Fuji Electric FRN0037F2S-4C — AC Drive (VFD) 480V

Fuji Electric FRN0037F2S-4C FRENIC Inverter, 3.7 A, 400 V

MPNFRN0037F2S-4C

Fuji Electric FRENIC Series High Performance Inverter, FRN0037F2S-4C, 3.7 A, three-phase 400 V, S = Basic type (IP20/IP00) enclosure.

$958.00Ref. price · indicative, final on quote
Sourced new & surplus through independent channelsAuthenticity-screened · ESD-safe packingListing updated Aug 2026

Specifications

FRN0037F2S-4C — Specifications
ParameterValue
EnclosureS = Basic type (IP20/IP00)
Power supply4 = Three-phase 400V
Product typeFRENIC Series High Performance Inverter
Applicable areaF
Development code2
Amperage rating value0037

Product details

The Fuji Electric FRN0037F2S-4C is a FRENIC Series High Performance Inverter rated for 3.7 A on a three-phase 400 V supply. The enclosure is S = Basic type (IP20/IP00), meaning it's intended for installation inside a panel where the IP20 rating covers the body and IP00 applies to the heatsink area — standard for this class of drive.

The 3.7 A rating (code 0037) is the drive's nominal output current, typically matching a 1.5 kW to 2.2 kW motor at 400 V depending on the motor's efficiency and duty cycle. The three-phase 400 V input (code 4) is standard for European and Asian industrial mains.

Frequently asked questions

What is the enclosure rating for FRN0037F2S-4C?

The enclosure is S = Basic type (IP20/IP00). IP20 covers the drive body; IP00 applies to the heatsink area, meaning it requires panel mounting with free airflow around the heatsink.

What is the input voltage requirement?

Three-phase 400 V (code 4 in the order code).

MPN
FRN0037F2S-4C
