Fuji Electric FRN0072F2S-4C — AC Drive (VFD) 480V

Fuji Electric FRN0072F2S-4C FRENIC Series High Performance I

MPNFRN0072F2S-4C

Fuji Electric FRENIC Series High Performance Inverter, FRN0072F2S-4C, 400V three-phase, 7.2A, S = Basic type (IP20/IP00).

$1,903.00Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026

Specifications

FRN0072F2S-4C — Specifications
ParameterValue
EnclosureS = Basic type (IP20/IP00)
Power supply4 = Three-phase 400V
Product typeFRENIC Series High Performance Inverter
Applicable areaF
Development code2
Amperage rating value0072

Product details

The Fuji Electric FRN0072F2S-4C is a FRENIC Series High Performance Inverter rated for 7.2A on a 400V three-phase supply. The 'S' in the order code denotes a basic enclosure type — IP20/IP00 — meaning the drive body is protected against touch and solid objects larger than 12 mm, but the internal bus and control board are exposed once the cover is off. That's standard for panel-mount drives; you'll need a separate enclosure if the environment has conductive dust or washdown.

The 7.2A rating is the continuous output current for the drive's nominal motor load. On a 400V three-phase supply, that works out to roughly 3.7 kW (5 HP) for a standard induction motor. The IP20/IP00 enclosure means the drive is designed for a clean, dry electrical panel — not for direct mounting in a washdown or dusty area. If the application is on a lube route or near rotating equipment, plan for a separate NEMA 4X or IP54 cabinet.

Frequently asked questions

What is FRN0072F2S-4C's listed enclosure (S = Basic type (IP20/IP00)) on this component line?

The 'S' in the order code corresponds to a basic enclosure type rated IP20/IP00 — touch-safe on the outside but open to internal bus exposure.

MPN
FRN0072F2S-4C
