Fuji Electric FRN1.5G1S-4J
MPNFRN1.5G1S-4J
FRENIC MEGA Series Multifunction Inverter
$1,308.47Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for machine-down parts
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Sep 2026
Specifications
| Parameter | Value |
|---|---|
| HD | High Duty spec 200% for 3 sec, 150% for 1min |
| Weight | 2.6 Kg |
| Product type | FRENIC MEGA Series Multifunction Inverter |
| Starting frequency | 0.0 to 60.0Hz, Braking time: 0.0 to 30.0s, Braking level:0 to 100% |
| Overload capability | 150% for 1min, 200% for 3.0s |
| Rated frequency [Hz] | 50, 60Hz |
| Rated current [A] (*4) | 4 |
| Rated voltage [V] (*3) | Three-phase 380 to 480V (with AVR) |
| Rated capacity [kVA] (*2) | 2.8 |
| Nominal applied motor [kW] | 1.5 |
| UL508C, C22.2No.14 (pending), EN61800-5-1 | 2003 |
| Main circuit power phases, voltage, frequency | Three-phase 380 to 480V, 50/60Hz |
| Auxiliary control power input phases, voltage, frequency | Single-phase 380 to 480V, 50/60Hz |
MPN
FRN1.5G1S-4J
